3.3 Main Circuit Wiring
SIEPCYEUOQ2V01A Q2V Technical Manual 65
Model Terminal
Recommended
Gauge
mm
2
Applicable Gauge
mm
2
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
Size Shape
4004
R/L1, S/L2, T/L3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4005
R/L1, S/L2, T/L3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4007
R/L1, S/L2, T/L3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4009
R/L1, S/L2, T/L3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 2 2 - 3.5 8 M3
0.5 - 0.6
(4.4 - 5.3)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4012
R/L1, S/L2, T/L3 2 2 - 3.5 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 2 2 - 3.5 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 3.5 2 - 5.5 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 2 2 - 3.5 10 M4
1.5 - 1.7
(13.5 - 15)
3.5
*2
2 - 5.5
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
