Monitor screen numbers are listed below:
Display <a>: Power Status Display
No. Indication Description
a1 (None) There is input to the main power supply/control power supply.
a2 CTRL There is input to the control power supply.
a3 24V The device runs with 24V input to P+/P-.
Display <b>: Display of SET Function Operation Status
No. Indication Description
b1 M1 The [SET] terminal is not selected or the [SET] terminal is selected but the function is dis-
abled. (common setting and first setting are enabled)
b2 M2 The [SET] terminal is selected and the function is enabled. (common setting and second
setting are enabled)
Display <c>: Selection of Parameter Display
No. Indication Description
c1 (None) All-parameter display mode.
c2 UTL Individual-function display mode.
c3 USR User-setting display mode.
c4 CMP Data-comparison display mode.
c5 MON Monitor display mode.
Display <d>: List of Monitor Screen Numbers
No. Name
Screen
number
1 Three-line monitor screen H01
2 Setting screen for rotating direction of LCD operator H02
3 Setting screen H03
4 Monitor with large characters H04
5 Selection screen for parameter code H05
6 Trip history H06
7 Trip currently occurring H07
8 Detailed trip history screen H08
9 Retry history H09
10 Detailed retry history screen H10
11 Detailed screen for limitation status icon H11
12 Home screen option o01
13 Inverter name setting o02
14 Selection of data displayed at the bottom center o03
15 Menu screen M01
16 R/W function screen R01
17 Screen for selecting data uploaded using the R/W function R02
18 Screen for selecting saving location for data uploaded using the R/W function R03
19 Screen for displaying progress status of uploading using the R/W function R04
20 Screen for selecting data downloaded using the R/W function R05
To Next Page
