4 Test Run
4 - 12
High-function General-purpose Inverter RX2 Series User’s Manual
Parameter
Item Parameter Data Description
Simulation mode enable [PA-20]
00 Disable
01 Enable
Error code selection for Alarm test [PA-21] 000 to 255
Issues a set error. Errors
not listed in the selection
do not occur.
Output current monitor optional
output enable
DC-bus voltage monitor optional
output enable
Output voltage monitor optional
output enable
Output torque monitor optional
output enable
Start with frequency matching
optional Setting enable
[PA-22]
[PA-24]
[PA-26]
[PA-28]
[PA-30]
00 Disable
01 Enable (Parameter setting)
02 Enable (Setting by [Ai1])
03 Enable (Setting by [Ai2])
04 Enable (Setting by [Ai3])
05 (Reserved)
06 (Reserved)
07 (Reserved)
Output current monitor optional
output value setting
[PA-23]
0.0 to 3.0
× Inverter rated current (A)
*1
*1. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting
path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00
(A,V). When the data of [CF-11] Resister data selection is not set to 00 (A,V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A,V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
Treats the set values as
internal output values.
DC-bus voltage monitor optional
value output
[PA-25]
200V class: 0.0 to 450.0 (Vdc)
400V class: 0.0 to 900.0 (Vdc)
Treats the set values as
internal output values.
Output voltage monitor optional
output value setting
[PA-27]
200V class: 0.0-300.0(V)
400V class: 0.0-600.0(V)
Treats the set values as
internal output values.
Output torque monitor optional
output value setting
[PA-29] -500.0 to 500.0(%)
Treats the set values as
internal output values.
Start with frequency matching
optional value setting
[PA-31] 0.00 to 590.00(Hz)
Treats the set values as
internal output values.
