Omron RX2 Series User Manual

8 Applied Settings
8 - 30
High-function General-purpose Inverter RX2 Series User’s Manual
 Input Terminal Function
 Data Monitor Function
Item Terminal name Data Description
PID2 disable function [PID2] 043
Disables the PID2 function by turning ON the termi-
nal function.
Frequency equivalent to the target value of PID2 will
be commanded when the terminal is turned ON.
PID2 I control integral
value clear
[PIDC2] 044 Clears the integral value of PID2 control.
PID3 disable function [PID3] 045
Disables the PID3 function by turning ON the termi-
nal function.
Frequency equivalent to the target value of PID3 will
be commanded when the terminal is turned ON.
PID3 I control integral
value clear
[PIDC3] 046 Clears the integral value of PID3 control.
PID4 disable function [PID4] 047
Disables the PID4 function by turning ON the termi-
nal function.
Frequency equivalent to the target value of PID4 will
be commanded when the terminal is turned ON.
PID4 I control integral
value clear
[PIDC4] 048 Clears the integral value of PID4 control.
PID output switch 1 [PIO1] 056
Switches PID output by a combination of PIO1 and
PIO2.
PID output switch 2 [PIO2] 057
Item Parameter Data Description
PID2 target value [FA-36]
-100.00 to 100.00(%)
*1
*1. Data range varies depending on the data from [AJ-04] to [AJ-06].
Displays the target value of PID2.
Changeable when [AJ-07] = 09.
PID2 feedback monitor [db-36]
-100.00 to 100.00(%)
*1
Displays the feedback value of PID2.
PID2 output monitor [db-55]
-100.00 to 100.00(%)
Displays the output value of PID2.
PID2 deviation monitor [db-56]
-200.00 to 200.00(%)
Displays the deviation of PID2.
PID3 target value [FA-38]
-100.00 to 100.00(%)
*2
*2. Data range varies depending on the data from [AJ-24] to [AJ-26].
Displays the target value of PID3.
Changeable when [AJ-27] = 09.
PID3 feedback monitor [db-38]
-100.00 to 100.00(%)
*2
Displays the feedback value of PID3.
PID3 output monitor [db-57]
-100.00 to 100.00(%)
Displays the output value of PID3.
PID3 deviation monitor [db-58]
-200.00 to 200.00(%)
Displays the deviation of PID3.
PID4 target value [FA-40]
-100.00 to 100.00(%)
*3
*3. Data range varies depending on the data from [AJ-44] to [AJ-46].
Displays the target value of PID4.
Changeable when [AJ-47] = 09.
PID4 feedback monitor [db-40]
-100.00 to 100.00(%)
*3
Displays the feedback value of PID4.
PID4 output monitor [db-59]
-100.00 to 100.00(%)
Displays the output value of PID4.
PID4 deviation monitor [db-60]
-200.00 to 200.00(%)
Displays the deviation of PID4.
