8 - 35
8 Applied Settings
High-function General-purpose Inverter RX2 Series User’s Manual
8-1 PID Control
8
8-1-6 PID Signal Output
 Parameter
 Feedback Comparison Signal
Item
Terminal
name
Data Description
Default
data
PID1 Feedback com-
pare signal turn-off
level
[AH-73]
0.00 to
100.00(%)
FBV1 signal output OFF judgment level 100.00
PID1 Feedback com-
pare signal turn-on
level
[AH-74]
0.00 to
100.00(%)
FBV1 signal output ON judgment level 0.00
PID2 Feedback com-
pare signal turn-off
level
[AJ-18]
0.00 to
100.00(%)
FBV2 signal output OFF judgment level 100.00
PID2 Feedback com-
pare signal turn-on
level
[AJ-19]
0.00 to
100.00(%)
FBV2 signal output ON judgment level 0.00
PID3 Feedback com-
pare signal turn-off
level
[AJ-38]
0.00 to
100.00(%)
FBV3 signal output OFF judgment level 100.00
PID3 Feedback com-
pare signal turn-on
level
[AJ-39]
0.00 to
100.00(%)
FBV3 signal output ON judgment level 0.00
PID4 Feedback com-
pare signal turn-off
level
[AJ-58]
0.00 to
100.00(%)
FBV4 signal output OFF judgment level 100.00
PID4 Feedback com-
pare signal turn-on
level
[AJ-59]
0.00 to
100.00(%)
FBV4 signal output ON judgment level 0.00
Item Terminal name Data Description
PID1 feedback com-
parison signal
[FBV1] 046
PID1 feedback signal [FBV1]
OFF: Exceeded the OFF level.
ON: Went below the ON level.
PID2 feedback com-
parison signal
[FBV2] 048
PID2 feedback signal [FBV2]
OFF: Exceeded the OFF level.
ON: Went below the ON level.
PID3 feedback com-
parison signal
[FBV3] 090
PID3 feedback signal [FBV3]
OFF: Exceeded the OFF level.
ON: Went below the ON level.
PID4 feedback com-
parison signal
[FBV4] 092
PID4 feedback signal [FBV4]
OFF: Exceeded the OFF level.
ON: Went below the ON level.
