8 Applied Settings
8 - 38
High-function General-purpose Inverter RX2 Series User’s Manual
Parameter
Item Parameter Data Description
Default
data
PID1 unit selection [AH-03]
*1
*1. Refer to the unit table in the next section.
Sets the unit of PID1 display conversion
parameter.
1
PID1 scale adjust-
ment (0%)
[AH-04] -10000 to 10000
Sets the criteria of input 0% of PID1 dis-
play conversion parameter.
0
PID1 scale adjust-
ment (100%)
[AH-05] -10000 to 10000
Sets the criteria of input 100% of PID1
display conversion parameter.
10000
PID1 scale adjust-
ment (point position)
[AH-06]
00 00000.
02
01 0000.0
02 000.00
03 00.000
04 0.0000
PID2 unit selection [AJ-03]
*1
Sets the unit of PID2 display conversion
parameter.
01
PID2 scale adjust-
ment (0%)
[AJ-04] -10000 to 10000
Sets the criteria of input 0% of PID2 dis-
play conversion parameter.
0
PID2 scale adjust-
ment (100%)
[AJ-05] -10000 to 10000
Sets the criteria of input 100% of PID2
display conversion parameter.
10000
PID2 scale adjust-
ment (point position)
[AJ-06]
00 00000.
02
01 0000.0
02 000.00
03 00.000
04 0.0000
PID3 unit selection [AJ-23]
*1
Sets the unit of PID3 display conversion
parameter.
01
PID3 scale adjust-
ment (0%)
[AJ-24] -10000 to 10000
Sets the criteria of input 0% of PID3 dis-
play conversion parameter.
0
PID3 scale adjust-
ment (100%)
[AJ-25] -10000 to 10000
Sets the criteria of input 100% of PID3
display conversion parameter.
10000
PID3 scale adjust-
ment (point position)
[AJ-26]
00 00000.
02
01 0000.0
02 000.00
03 00.000
04 0.0000
PID4 unit selection [AJ-43]
*1
Sets the unit of PID4 display conversion
parameter.
01
PID4 scale adjust-
ment (0%)
[AJ-44] -10000 to 10000
Sets the criteria of input 0% of PID4 dis-
play conversion parameter.
0
PID4 scale adjust-
ment (100%)
[AJ-45] -10000 to 10000
Sets the criteria of input 100% of PID4
display conversion parameter.
10000
PID4 scale adjust-
ment (point position)
[AJ-46]
00 00000.
02
01 0000.0
02 000.00
03 00.000
04 0.0000
