8 Applied Settings
8 - 118
High-function General-purpose Inverter RX2 Series User’s Manual
Position Control Related Parameters
Item
Function
Code
Data/
Data Range
Description
Default
data
Position control mode
selection
[AE-56]
00 With limit
00
01 Without limit
Teach-in function tar-
get selection
[AE-60]
00 Multistage position command 0 (AE-20)
00
01 Multistage position command 1 (AE-22)
02 Multistage position command 2 (AE-24)
03 Multistage position command 3 (AE-26)
04 Multistage position command 4 (AE-28)
05 Multistage position command 5 (AE-30)
06 Multistage position command 6 (AE-32)
07 Multistage position command 7 (AE-34)
08 Multistage position command 8 (AE-36)
09 Multistage position command 9 (AE-38)
10 Multistage position command 10 (AE-40)
11 Multistage position command 11 (AE-42)
12 Multistage position command 12 (AE-44)
13 Multistage position command 13 (AE-46)
14 Multistage position command 14 (AE-48)
15 Multistage position command 15 (AE-50)
Current position sav-
ing at power-off
[AE-61]
00 Disabled
00
01 Enabled
Preset position data [AE-62]
Condition 1:
-268435455 to
+268435455
Condition 2:
-1073741823 to
+1073741823
Condition 1: Except for the condition 2
Condition 2: [AA121] = 10, [AA123] = 03
0
Reset selection [CA-72]
02 Enabled Only at Trip (On to Release)
-
03 Enabled Only at Trip (Off to Release)
Input terminal function
[CA-01] to
[CA-11]
072 PCLR: Position deviation clear
-
076 CP1: Position command selection 1
077 CP2: Position command selection 2
078 CP3: Position command selection 3
079 CP4: Position command selection 4
