9 - 53
9 Communications Functions
High-function General-purpose Inverter RX2 Series User’s Manual
9-5 Modbus Communication Register Number List
9
9-5-4 Group A Register List
319Dh 319Ch PID1 enable AH-01 R/W
00: Disabled
01: Enabled Without reverse out-
put
02: Enabled With reverse output
-
319Eh 319Dh PID1 deviation inverse AH-02 R/W
00: Disabled
01: Enabled
-
319Fh 319Eh Unit selection for PID1 AH-03 R/W
See <Unit options> on page
C-70 at the end of Appendices C
1
31A0h 319Fh
PID1 scale adjustment (at
0%)
AH-04 R/W -10000 to 10000 1
31A1h 31A0h
PID1 scale adjustment (at
100%)
AH-05 R/W -10000 to 10000 1
31A2h 31A1h
PID1 scale adjustment (point
position)
AH-06 R/W
00:0000.
01:0000.0
02:000.00
03:00.000
04:0.0000
-
31A3h 31A2h
Input source selection of
Set-point for PID1
AH-07 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
-
31A6h 31A5h
Set-point-1 setting for PID1
AH-10
(HIGH)
R/W
-100.00 to 100.00
*4
Unit differs
depending
on setting
[AH-03]
[AH-06].
31A7h 31A6h
AH-11
(LOW)
R/W
31A8h 31A7h
PID1 Multi stage set-point 1
setting
AH-12
(HIGH)
R/W
Unit differs
depending
on setting
[AH-03]
[AH-06].
31A9h 31A8h
AH-13
(LOW)
R/W
31Aah 31A9h
PID1 Multi stage set-point 2
setting
AH-14
(HIGH)
R/W
Unit differs
depending
on setting
[AH-03]
[AH-06].
31Abh 31Aah
AH-15
(LOW)
R/W
31Ach 31Abh
PID1 Multi stage set-point 3
setting
AH-16
(HIGH)
R/W
Unit differs
depending
on setting
[AH-03]
[AH-06].
31Adh 31Ach
AH-17
(LOW)
R/W
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
