9 Communications Functions
9 - 52
High-function General-purpose Inverter RX2 Series User’s Manual
30FCh 30FBh
Brake Wait Time for Stopping,
1st-motor (Reverse side)
AF140 R/W 0 to 500 0.01(s)
30FDh 30FCh
Brake Wait Time for Confir-
mation, 1st-motor (Reverse
side)
AF141 R/W 0 to 500 0.01(s)
30Feh 30FDh
Brake Release Frequency
Setting, 1st-motor (Reverse
side)
AF142 R/W 0 to 59000 0.01(Hz)
30FFh 30FEh
Brake Release Current Set-
ting, 1st-motor (Reverse side)
AF143 R/W
(0.0 to 2.0)
× Inverter rated current
*3
0.1(A)
3100h 30FFh
Braking Frequency, 1st-motor
(Reverse side)
AF144 R/W 0 to 59000 0.01(Hz)
3106h 3105h
Brake open delay time,
1st-motor
AF150 R/W 0 to 200 0.01(s)
3107h 3106h
Brake close delay time,
1st-motor
AF151 R/W 0 to 200 0.01(s)
3108h 3107h
Brake answer back check
time, 1st-motor
AF152 R/W 0 to 500 0.01(s)
3109h 3108h
Servo lock/ DC injection time
at start, 1st-motor
AF153 R/W 0 to 1000 0.01(s)
310Ah 3109h
Servo lock/ DC injection time
at stop, 1st-motor
AF154 R/W 0 to 1000 0.01(s)
3139h 3138h Jump frequency 1, 1st-motor AG101 R/W 0 to 59000 0.01(Hz)
313Ah 3139h
Jump frequency width 1,
1st-motor
AG102 R/W 0 to 1000 0.01(Hz)
313Bh 313Ah Jump frequency 2, 1st-motor AG103 R/W 0 to 59000 0.01(Hz)
313Ch 313Bh
Jump frequency width 2,
1st-motor
AG104 R/W 0 to 1000 0.01(Hz)
313Dh 313Ch Jump frequency 3, 1st-motor AG105 R/W 0 to 59000 0.01(Hz)
313Eh 313Dh
Jump frequency width 3,
1st-motor
AG106 R/W 0 to 1000 0.01(Hz)
3142h 3141h
Acceleration stop frequency
setting, 1st-motor
AG110 R/W 0 to 59000 0.01(Hz)
3143h 3142h
Acceleration stop time setting,
1st-motor
AG111 R/W 0 to 600 0.1(s)
3144h 3143h
Deceleration stop frequency
setting, 1st-motor
AG112 R/W 0 to 59000 0.01(Hz)
3145h 3144h
Deceleration stop time set-
ting, 1st-motor
AG113 R/W 0 to 600 0.1(s)
314Ch 314Bh Jogging frequency AG-20 R/W 0 to 1000 0.01(Hz)
314Dh 314Ch Jogging stop mode selection AG-21 R/W
00: Disabled during FRS opera-
tion at stop
01: Disabled during deceleration
stop operation
02: Disabled during DB operation
at stop
03: Enabled during FRS opera-
tion at stop
04: Enabled during deceleration
stop operation
05: Enabled during DB operation
at stop
-
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
