Omron RX2 Series - Page 650

9 Communications Functions
9 - 58
High-function General-purpose Inverter RX2 Series User’s Manual
3201h 3200h PID2 enable AJ-01 R/W
00: Disabled
01: Enabled Without reverse out-
put
02: Enabled With reverse output
-
3202h 3201h PID2 deviation inverse AJ-02 R/W
00: Disabled
01: Enabled
-
3203h 3202h PID2 unit selection AJ-03 R/W
See <Unit options> on page
C-70 at the end of Appendices C
-
3204h 3203h
PID2 scale adjustment (at
0%)
AJ-04 R/W -10000 to 10000 1
3205h 3204h
PID2 scale adjustment (at
100%)
AJ-05 R/W -10000 to 10000 1
3206h 3205h
PID2 scale adjustment (point
position)
AJ-06 R/W
00:0000.
01:0000.0
02:000.00
03:00.000
04:0.0000
-
3207h 3206h
Input source selection of
Set-point for PID2
AJ-07 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
15: PID calculation
-
320Ah 3209h
Set-point setting for PID2
AJ-10
(HIGH)
R/W
-100.00 to 100.00
*1
Unit differs
depending
on setting
[AJ-03]
[AJ-06].
320Bh 320Ah
AJ-11
(LOW)
R/W
320Ch 320Bh
Input source selection of Pro-
cess data for PID2
AJ-12 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
-
320Dh 320Ch PID2 proportional gain AJ-13 R/W 0 to 1000 0.1
320Eh 320Dh PID2 integral time constant AJ-14 R/W 0 to 36000 0.1(s)
320Fh 320Eh PID2 derivative gain AJ-15 R/W 0 to 10000 0.01(s)
3210h 320Fh PID2 output range AJ-16 R/W 0 to 10000 0.01(%)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
