9 - 59
9 Communications Functions
High-function General-purpose Inverter RX2 Series User’s Manual
9-5 Modbus Communication Register Number List
9
9-5-4 Group A Register List
3211h 3210h PID2 Deviation over level AJ-17 R/W 0 to 10000 0.01(%)
3212h 3211h
PID2 Feedback compare sig-
nal turn-off level
AJ-18 R/W 0 to 10000 0.01(%)
3213h 3212h
PID2 Feedback compare sig-
nal turn-on level
AJ-19 R/W 0 to 10000 0.01(%)
3215h 3214h PID3 enable AJ-21 R/W
00 (Disabled)/
01 (Enabled Without reverse out-
put)/
02 (Enabled With reverse output)
-
3216h 3215h PID3 deviation inverse AJ-22 R/W
00: Disabled
01: Enabled
-
3217h 3216h PID3 unit selection AJ-23 R/W
See <Unit options> on page
C-70 at the end of Appendices C
-
3218h 3217h
PID3 scale adjustment (at
0%)
AJ-24 R/W -10000 to 10000 1
3219h 3218h
PID3 scale adjustment (at
100%)
AJ-25 R/W -10000 to 10000 1
321Ah 3219h
PID3 scale adjustment (point
position)
AJ-26 R/W
00:0000.
01:0000.0
02:000.00
03:00.000
04:0.0000
-
321Bh 321Ah
Input source selection of
Set-point for PID3
AJ-27 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
-
321Eh 321Dh
Set-point setting for PID3
AJ-30
(HIGH)
R/W
-100.00 to 100.00
*4
Unit differs
depending
on setting
[AJ-23]
[AJ-26].
321Fh 321Eh
AJ-31
(LOW)
R/W
3220h 321Fh
Input source selection of Pro-
cess data for PID3
AJ-32 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
-
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
