9 Communications Functions
9 - 60
High-function General-purpose Inverter RX2 Series User’s Manual
3221h 3220h PID3 proportional gain AJ-33 R/W 0 to 1000 0.1
3222h 3221h PID3 integral time constant AJ-34 R/W 0 to 36000 0.1(s)
3223h 3222h PID3 derivative gain AJ-35 R/W 0 to 10000 0.01(s)
3224h 3223h PID3 output range AJ-36 R/W 0 to 10000 0.01(%)
3225h 3224h PID3 Deviation over level AJ-37 R/W 0 to 10000 0.01(%)
3226h 3225h
PID3 Feedback compare sig-
nal turn-off level
AJ-38 R/W 0 to 10000 0.01(%)
3227h 3226h
PID3 Feedback compare sig-
nal turn-on level
AJ-39 R/W 0 to 10000 0.01(%)
3229h 3228h PID4 enable AJ-41 R/W
00: Disabled
01: Enabled Without reverse out-
put
02: Enabled With reverse output
1
322Ah 3229h PID4 deviation inverse AJ-42 R/W
00: Disabled
01: Enabled
1
322Bh 322Ah PID4 unit selection AJ-43 R/W
See <Unit options> on page
C-70 at the end of Appendices C
1
322Ch 322Bh
PID4 scale adjustment (at
0%)
AJ-44 R/W -10000 to 10000 1
322Dh 322Ch
PID4 scale adjustment (at
100%)
AJ-45 R/W -10000 to 10000 1
322Eh 322Dh
PID4 scale adjustment (point
position)
AJ-46 R/W
0:00000.
01:0000.0
02:000.00
03:00.000
04:0.0000
-
322Fh 322Eh
Input source selection of
Set-point for PID4
AJ-47 R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
-
3232h 3221h
Set-point setting for PID4
AJ-50
(HIGH)
R/W
-100.00 to 100.00
*4
Unit differs
depending
on setting
[AJ-43]
[AJ-46].
3233h 3232h
AJ-51
(LOW)
R/W
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data Resolution
