9 Communications Functions
9 - 74
High-function General-purpose Inverter RX2 Series User’s Manual
370Eh 370Dh
Pulse train frequency Bias
value
CA-94 R/W -1000 to 1000 0.1(%)
370Fh 370Eh
Pulse train frequency High
Limit
CA-95 R/W 0 to 1000 0.1(%)
3710h 370Fh
Pulse train frequency detec-
tion low level
CA-96 R/W 0 to 1000 0.1(%)
3711h 3710h
Comparing match output
ON-level for Pulse count
CA-97 R/W 0 to 65535 1
3712h 3711h
Comparing match output
OFF-level for Pulse count
CA-98 R/W 0 to 65535 1
3713h 3712h
Comparing match output
Maximum value for Pulse
count
CA-99 R/W 0 to 65535 1
3715h 3714h
Filter time constant of Termi-
nal [Ai1]
Cb-01 R/W 1 to 500 1(ms)
3717h 3716h Start value of Terminal [Ai1] Cb-03 R/W 0 to 10000 0.01(%)
3718h 3717h End value of Terminal [Ai1] Cb-04 R/W 0 to 10000 0.01(%)
3719h 3718h Start rate of Terminal [Ai1] Cb-05 R/W 0 to 1000 (Cb-06) 0.1(%)
371Ah 3719h End rate of Terminal [Ai1] Cb-06 R/W (Cb-05) 0 to 1000 0.1(%)
371Bh 371Ah
Start point selection of Termi-
nal [Ai1]
Cb-07 R/W
00: Start amount
01: 0%
-
371Fh 371Eh
Filter time constant of Termi-
nal [Ai2]
Cb-11 R/W 1 to 500 1(ms)
3721h 3720h Start value of Terminal [Ai2] Cb-13 R/W 0 to 10000 0.01(%)
3722h 3721h End value of Terminal [Ai2] Cb-14 R/W 0 to 10000 0.01(%)
3723h 3722h Start rate of Terminal [Ai2] Cb-15 R/W 0 to 1000 (Cb-16)0.1(%)
3724h 3723h End rate of Terminal [Ai2] Cb-16 R/W (Cb-15) 0 to 1000 0.1(%)
3725h 3724h
Start point selection of Termi-
nal [Ai2]
Cb-17 R/W
00: Start amount
01: 0%
-
3729h 3728h
Filter time constant of Termi-
nal [Ai3]
Cb-21 R/W 1 to 500 1(ms)
372Ah 3729h Terminal [Ai3] selection Cb-22 R/W
00: Single
01: Added to Ai1/Ai2: with revers-
ibility
02: Added to Ai1/Ai2: without
reversibility
-
372Bh 372Ah Start value of Terminal [Ai3] Cb-23 R/W -10000 to 10000 0.01%
372Ch 372Bh End value of Terminal [Ai3] Cb-24 R/W -10000 to 10000 0.01%
372Dh 372Ch Start rate of Terminal [Ai3] Cb-25 R/W -1000 to 1000 (Cb-26) 0.1(%)
372Eh 372Dh End rate of Terminal [Ai3] Cb-26 R/W (Cb-25)-1000 to 10000.1(%)
3732h 3731h
[Ai1] Voltage/Current
zero-gain adjustment
Cb-30 R/W -10000 to 10000 0.01(%)
3733h 3732h
[Ai1] Voltage/Current gain
adjustment
Cb-31 R/W 0 to 20000 0.01(%)
3734h 3733h
[Ai2] Voltage/Current
zero-gain adjustment
Cb-32 R/W -10000 to 10000 0.01(%)
3735h 3734h
[Ai2] Voltage/Current gain
adjustment
Cb-33 R/W 0 to 20000 0.01(%)
3736h 3735h
[Ai3] Voltage/Current
zero-gain adjustment
Cb-34 R/W -10000 to 10000 0.01(%)
3737h 3736h [Ai3] Voltage gain adjustment Cb-35 R/W 0 to 20000 0.01(%
)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
