9 Communications Functions
9 - 80
High-function General-purpose Inverter RX2 Series User’s Manual
38Bah 38B9h
EzCOM Start method
selection
CF-22 R/W
00: ECOM terminal
01: (Modbus spec)
-
38BBh 38BAh EzCOM data size CF-23 R/W 01 to 05 1
38BCh 38BBh EzCOM destination address 1 CF-24 R/W 1 to 47 1
38BDh 38BCh EzCOM destination resister 1 CF-25 R/W 0000 to FFFF 1
38Beh 38BDh EzCOM source resister 1 CF-26 R/W 0000 to FFFF 1
38BFh 38BEh EzCOM destination address 2 CF-27 R/W 1 to 247 1
38C0h 38BFh EzCOM destination resister 2 CF-28 R/W 0000 to FFFF 1
38C1h 38C0h EzCOM source resister 2 CF-29 R/W 0000 to FFFF 1
38C2h 38C1h EzCOM destination address 3 CF-30 R/W 1 to 247 1
38C3h 38C2h EzCOM destination resister 3 CF-31 R/W 0000 to FFFF 1
38C4h 38C3h EzCOM source resister 3 CF-32 R/W 0000 to FFFF 1
38C5h 38C4h EzCOM destination address 4 CF-33 R/W 1 to 247 1
38C6h 38C5h EzCOM destination resister 4 CF-34 R/W 0000 to FFFF 1
38C7h 38C6h EzCOM source resister 4 CF-35 R/W 0000 to FFFF 1
38C8h 38C7h EzCOM destination address 5 CF-36 R/W 1 to 247 1
38C9h 38C8h EzCOM destination resister 5 CF-37 R/W 0000 to FFFF 1
38Cah 38C9h EzCOM source resister 5 CF-38 R/W 0000 to FFFF 1
38D6h 38D5h
USB communication Node
allocation
CF-50 R/W 1 to 247 1
5F51h 5F50h
Low current signal output
mode selection, 2nd-motor
CE201 R/W Same as CE101 -
5F52h 5F51h
Low current detection level 1,
2nd-motor
CE202 R/W Same as CE102 0.1(A)
5F53h 5F52h
Low current detection level 2,
2nd-motor
CE203 R/W Same as CE103 0.1(A)
5F55h 5F54h
Over current signal output
mode selection, 2nd-motor
CE205 R/W Same as CE105 -
5F56h 5F55h
Over current detection level 1,
2nd-motor
CE206 R/W Same as CE106 0.1(A)
5F57h 5F56h
Over current detection level 2,
2nd-motor
CE207 R/W Same as CE107 0.1(A)
5F64h 5F63h
Over torque level (Forward
driving), 2nd-motor
CE220 R/W Same as CE120 0.1(%)
5F65h 5F64h
Over torque level (Reverse
regenerative), 2nd-motor
CE221 R/W Same as CE121 0.1(%)
5F66h 5F65h
Over torque level (Reverse
driving), 2nd-motor
CE222 R/W Same as CE122 0.1(%)
5F67h 5F66h
Over torque level (Forward
regenerative), 2nd motor
CE223 R/W Same as CE123 0.1(%)
*1. 0 to 65535 (Register No. of d, F code)
*2. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00 (A, V).
When the data of [CF-11] Resister data selection is not set to 00 (A, V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A, V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
Register
No.
Modbus
register
spec. No.
Function name
Parameter
No.
R/W Monitor or setting data
Resolution
