Omron RX2 Series - Page 737

11 - 39
11 Options
High-function General-purpose Inverter RX2 Series User’s Manual
11-7 Input Noise Filter
(Model: 3G3AX-NFI)
11
11-7-2 External Dimensions
3G3AX-NFI25/NFI26/NFI45/NFI46/NFI47
Inverter side
65
90
(16)
155
165
2-φ4.5
M6
(95)
Power supply side
2-4.5×6
95
L1 L2 L3
L1' L2' L3'
Ground terminal
