C003 Selection of intelligent input terminal 3 CA-03
C004 Selection of intelligent input terminal 4 CA-04
C005 Selection of intelligent input terminal 5 CA-05
C006 Selection of intelligent input terminal 6 CA-06
C007 Selection of intelligent input terminal 7 CA-07
C008 Selection of intelligent input terminal 8 CA-08
C011
Selection of intelligent input terminal 1a/b
(NO/NC)
CA-21
C012
Selection of intelligent input terminal 2a/b
(NO/NC)
CA-22
C013
Selection of intelligent input terminal 3a/b
(NO/NC)
CA-23
C014
Selection of intelligent input terminal 4a/b
(NO/NC)
CA-24
C015
Selection of intelligent input terminal 5a/b
(NO/NC)
CA-25
C016
Selection of intelligent input terminal 6a/b
(NO/NC)
CA-26
C017
Selection of intelligent input terminal 7a/b
(NO/NC)
CA-27
C018
Selection of intelligent input terminal 8a/b
(NO/NC)
CA-28
C019 Selection of FW terminal a/b (NO/NC) CA-29 For CA-09 = FW (input terminal 001)
C021 Selection of intelligent output terminal 11 CC-01
C022 Selection of intelligent output terminal 12 CC-02
C023 Selection of intelligent output terminal 13 CC-03
C024 Selection of intelligent output terminal 14 CC-04
C025 Selection of intelligent output terminal 15 CC-05
C026 Selection of intelligent relay terminal CC-07
C027 FM selection Cd-03
C028 AM selection Cd-04
C029 AMI selection Cd-05
C030 Reference value of digital current monitor
Configured with Cd-02 (settings need
to be checked)
C031
Selection of intelligent output terminal 11a/b
(NO/NC)
CC-11
C032
Selection of intelligent output terminal 12a/b
(NO/NC)
CC-12
C033
Selection of intelligent output terminal 13a/b
(NO/NC)
CC-13
C034
Selection of intelligent output terminal 14a/b
(NO/NC)
CC-14
C035
Selection of intelligent output terminal 15a/b
(NO/NC)
CC-15
C036 Selection of intelligent relay a/b (NO/NC) CC-17
C038 Low current signal output mode selection CE101
Addition of individual settings for sec-
ond control
C039 Low current detection level CE102
Addition of individual settings for sec-
ond control
C040
Overload advance notice signal output
mode selection
CE105
Addition of individual settings for sec-
ond control
C041 Overload advance notice level CE106
Add
i
tion of individual settings for sec-
ond control
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
