Appendices A Technical Information
A - 22
High-function General-purpose Inverter RX2 Series User’s Manual
P024 Position bias volume AE-08
P025
Selection of whether a secondary-resis-
tance correction is to be conducted.
HC113
Addition of individual settings for sec-
ond control
P026 Overspeed error detection level bb-80
P027 Overspeed deviation error detection level bb-81
P028 Numerator of motor gear ratio ob-03
P029 Denominator of motor gear ratio ob-04
P031 Acceleration or deceleration time input type AC-01
P032 Orientation stop position input type AE-10
P033 Torque command input selection Ad-01
P034 Torque command setting Ad-02
P035 Selection of pole at torque command by O2 Ad-03 Not limited to Ai3.
P036 Torque bias mode Ad-11
P037 Torque bias value Ad-12
P038 Torque bias polarity selection Ad-13
P039
Torque control speed limit value (for normal
rotation)
Ad-41
P040
Torque control speed limit value (for reverse
rotation)
Ad-42
P044
Timer setting for monitoring of DeviceNet
operation command
oA-11
P045
Operation setting at the time of communica-
tion error
oA-12
P046 OUTPUT assembly instance No. setting (reserved)
P047 INPUT assembly instance No. setting (reserved)
P048
Operation setting at the time of detection of
idle mode
(reserved)
P049
Setting of the number of poles for rotation
speed
Integrated to Hb103 (IM)/Hd103
(SM/PMM)
P055 Pulse string frequency scale ob-12
P056 Pulse string frequency time constant ob-13
P057 Position string bias volume ob-14
P058 Pulse string limit ob-15
P060 Position command 0 AE-20
P061 Position command 1 AE-22
P062 Position command 2 AE-24
P063 Position command 3 AE-26
P064 Position command 4 AE-28
P065 Position command 5 AE-30
P066 Position command 6 AE-32
P067 Position command 7 AE-34
P068 Zero return mode AE-70
P069 Zero return direction selection AE-71
P070 Low speed zero return frequency AE-72
P071 High speed zero return frequency AE-73
P072
Position range designation (forward rotation
side)
AE-52
P073
Position range designation (reverse rotation
side)
AE-54
P074 Teaching selection AE-60
P100
Simplified sequence function user parame-
ter U (00)
UE-10
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
To Next Page
