A - 21
Appendices A Technical Information
High-function General-purpose Inverter RX2 Series User’s Manual
A-2 Parameter Comparison
A
H206 Second stability constant HA210 * Adjustment may be required.
H306 Third stability constant Abolition of third control
H020 First motor R1 Hb110 * Adjustment may be required.
H220 Second motor R1 Hb210 * Adjustment may be required.
H021 First motor R2 Hb112 * Adjustment may be required.
H221 Second motor R2 Hb212 * Adjustment may be required.
H022 First motor L Hb114 * Adjustment may be required.
H222 Second motor L Hb214 * Adjustment may be required.
H023 First motor I0 Hb116 * Adjustment may be required.
H223 Second motor I0 Hb216 * Adjustment may be required.
H024 First motor J Hb118 * Adjustment may be required.
H224 Second motor J Hb218 * Adjustment may be required.
H030 First motor R1 (auto-tuning data) Hb110: Integration of setting location
H230 Second motor R1 (auto-tuning data) Hb210: Integration of setting location
H031 First motor R2 (auto-tuning data) Hb112: Integration of setting location
H231 Second motor R2 (auto-tuning data) Hb212: Integration of setting location
H032 First motor L (auto-tuning data) Hb114: Integration of setting location
H232 Second motor L (auto-tuning data) Hb214: Integration of setting location
H033 First motor I0 (auto-tuning data) Hb116: Integration of setting location
H233 Second motor I0 (auto-tuning data) Hb216: Integration of setting location
H034 First motor J (auto-tuning data) Hb118: Integration of setting location
H234 Second motor J (auto-tuning data) Hb218: Integration of setting location
H050 First PI proportional gain HA125 * Adjustment may be required.
H250 Second PI proportional gain HA225 * Adjustment may be required.
H051 First PI integrated gain HA126 * Adjustment may be required.
H251 Second PI integrated gain HA226 * Adjustment may be required.
H052 First P proportional gain HA127 * Adjustment may be required.
H252 Second P proportional gain HA227 * Adjustment may be required.
H060 First 0Hz range limiter HC110
H260 Second 0Hz range limiter HC210
H061 First 0Hz range SLV start boost volume HC112
H261 Second 0Hz range SLV start boost volume HC212
H070 For switching PI proportional gain HA128 * Adjustment may be required.
H071 For switching PI integrated gain HA129 * Adjustment may be required.
H072 For switching P proportional gain HA130 * Adjustment may be required.
H073 Gain switch time HA121
P001 Selection of operation at option 1 error oA-12
P002 Selection of operation at option 2 error oA-22
P011 Number of pulses of encoder ob-01
P012 V2 control mode selection AA123
P013 Pulse string mode selection ob-11
P014 Orientation stop position AE-11
P015 Orientation speed setting AE-12
P016 Orientation direction setting AE-13
P017 Positioning completion range setting AE-04
P018 Positioning completion delay time setting AE-05
P019
Electronic gear installation position selec-
tion
AE-01
P020 Numerator of electronic gear ratio AE-02
P021 Denominator of electronic gear ratio AE-03
P022 Positioning control feed forward gain AE-06
P023 Position loop gain AE-07
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
