Appendices A Technical Information
A - 20
High-function General-purpose Inverter RX2 Series User’s Manual
C132 Output 12 on-delay time CC-22
C133 Output 12 off-delay time CC-23
C134 Output 13 on-delay time CC-24
C135 Output 13 off-delay time CC-25
C136 Output 14 on-delay time CC-26
C137 Output 14 off-delay time CC-27
C138 Output 15 on-delay time CC-28
C139 Output 15 off-delay time CC-29
C140 Output RY on-delay time CC-32
C141 Output RY off-delay time CC-33
C142 Logical output signal 1 selection 1 CC-40
C143 Logical output signal 1 selection 2 CC-41
C144 Logical output signal 1 operator selection CC-42
C145 Logical output signal 2 selection 1 CC-43
C146 Logical output signal 2 selection 2 CC-44
C147 Logical output signal 2 operator selection CC-45
C148 Logical output signal 3 selection 1 CC-46
C149 Logical output signal 3 selection 2 CC-47
C150 Logical output signal 3 operator selection CC-48
C151 Logical output signal 4 selection 1 CC-49
C152 Logical output signal 4 selection 2 CC-50
C153 Logical output signal 4 operator selection CC-51
C154 Logical output signal 5 selection 1 CC-52
C155 Logical output signal 5 selection 2 CC-53
C156 Logical output signal 5 operator selection CC-54
C157 Logical output signal 6 selection 1 CC-55
C158 Logical output signal 6 selection 2 CC-56
C159 Logical output signal 6 operator selection CC-57
C160 Input terminal response time 1 CA-41
C161 Input terminal response time 2 CA-42
C162 Input terminal response time 3 CA-43
C163 Input terminal response time 4 CA-44
C164 Input terminal response time 5 CA-45
C165 Input terminal response time 6 CA-46
C166 Input terminal response time 7 CA-47
C167 Input terminal response time 8 CA-48
C168 Input terminal response time FW CA-49
C169
Multistage speed/position determination
time
CA-55
H001 Auto-tuning selection HA-01
H002 First motor constant selection
Abolition of selection (setting of IE3
motor)
H202 Second motor constant selection
Abolition of selection (setting of IE3
motor)
H003 First motor capacity selection Hb102
H203 Second motor capacity selection Hb202
H004 First selection of the number of motor poles Hb103
H204
Second selection of the number of motor
poles
Hb203
H005 First speed response HA115 * Adjustment may be required.
H205 Second speed response HA215 * Adjustment may be required.
H006 First stability constant HA110 * Adjustment may be required.
3G3RX-series V1 3G3RX2-series
Remarks
Display
code
Function name New code
