Appendices C Table of Parameters
C - 8
High-function General-purpose Inverter RX2 Series User’s Manual
dC-45 IM/SM (PMM) monitor
00 (Induction motor IM being selected)/
01 (Synchronous motor SM (permanent magnet motor PMM)
being selected)
dC-50 Firmware version monitor 0.000 to 99.255
dC-53 Firmware grade monitor 00 (Standard)
Monitor of Trip State
Code Name Data range
dE-01 Trip count monitor 0 to 65535
dE-11
Trip monitor 1 Factor 1 to 255
Trip monitor 1 Output frequency(with sign)(HIGT)
-59000 to 59000
Trip monitor 1 Output frequency(with sign)(LOW)
Trip monitor 1 Output current 0 to 65535
Trip monitor 1 P-N DC voltage 0 to 10000
Trip monitor 1 Inverter state
0 to 8
*1
Trip monitor 1 LAD state
0 to 5
*1
Trip monitor 1 INV control mode
0 to 11
*1
Trip monitor 1 Limit state
0 to 6
*1
Trip monitor 1 Special state
0 to 6
*1
Trip monitor 1 RUN time(HIGH)
0 to 1000000
Trip monitor 1 RUN time(LOW)
Trip monitor 1 Power ON time(HIGH)
0 to 1000000
Trip monitor 1 Power ON time(LOW)
Trip monitor 1 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Trip monitor 1 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Trip monitor 1 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
dE-12
Trip monitor 2 Factor 1 to 255
Trip monitor 2 Output frequency(with sign)(HIGT)
-59000 to 59000
Trip monitor 2 Output frequency(with sign)(LOW)
Trip monitor 2 Output current 0 to 65535
Trip monitor 2 P-N DC voltage 0 to 10000
Trip monitor 2 Inverter state
0 to 8
*1
Trip monitor 2 LAD state
0 to 5
*1
Trip monitor 2 INV control mode
0 to 11
*1
Trip monitor 2 Limit state
0 to 6
*1
Trip monitor 2 Special state
0 to 6
*1
Trip monitor 2 RUN time(HIGH)
0 to 1000000
Trip monitor 2 RUN time(LOW)
Trip monitor 2 Power ON time(HIGH)
0 to 2000000
Trip monitor 2 Power ON time(LOW)
Trip monitor 2 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Trip monitor 2 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Trip monitor 2 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
Code Name Data range
