C - 7
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-2 Monitor List
C
Monitors for Checking Internal Condition
Code Name Data range
dC-01 Inverter load type selection monitor 00 (very low duty)/01 (low duty/02 (normal duty)
dC-02 Rated current monitor 0.0 to 6553.5 (A)
dC-07
Speed command destination moni-
tor (main)
00 (disabled)/01 (Ai1)/02 (Ai2)/03 (Ai3)/04 (Reserved)/
05 (Reserved)/06 (Reserved)/07 (Multistage speed 0)/
08 (auxiliary speed)/09 (Multistage speed 1)/
10 (Multistage speed 2)/11 (Multistage speed 3)/
12 (Multistage speed 4)/13 (Multistage speed 5)/
14 (Multistage speed 6)/15 (Multistage speed 7)/
16 (Multistage speed 8)/17 (Multistage speed 9)/
18 (Multistage speed 10)/19 (Multistage speed 11)/
20 (Multistage speed 12)/21 (Multistage speed 13)/
22 (Multistage speed 14)/23 (Multistage speed 15)/
24 (JG)/25 (RS485)/26 (Option 1)/27 (Option 2)/
28 (Option 3)/29 (Pulse array (main unit))/
30 (Pulse array (Option))/31 (DriveProgramming)/
32 (PID)/33 (Reserved)/34 (AHD retention speed)
dC-08
Speed command destination moni-
tor (auxiliary)
dC-10
Operation command destination
monitor
00 ([FW]/[RV] terminal)/01 (3 wire)/
02 (RUN key on operator keypad)/03 (RS485 setting)/
04 (Option 1)/05 (Option 2)/06 (Option 3)
dC-15 Cooling fin temperature monitor -20.0 to 200.0 (°C)
dC-16 Life diagnostic monitor
LL to HH [L: normal/H: reduction of life]
[Left side ] (FAN life)
(lives of the capacitors on the circuit board) [Right side]
dC-20 Total start-up count 1 to 65535 (Counts)
dC-21 Power-on count 1 to 65535 (Counts)
dC-22
Cumulative operating hours monitor
during RUN
1 to 1000000 (hr)
dC-24 Cumulative power-on time 1 to 1000000 (hr)
dC-26
Cumulative operating time of cooling
fan
1 to 1000000 (hr)
dC-37 Detailed monitor for icon 2LIM
00 (Condition other than below)/
01 (Overcurrent suppression in process)/
02 (Overload being limited)/
03 (Overvoltage suppression in process)/
04 (Torque being limited)/
05 (Upper/lower limit and jump frequency setting being lim-
ited)/
06 (Setting of minimum frequency being limited)
dC-38 Detailed monitor for icon 2ALT
00 (Condition other than below)/
01 (Overload advance notice)/
02 (Motor thermal advance notice)/
03 (Controller thermal advance notice)/
04 (Motor overheat advance notice)
dC-39 Detailed monitor for icon 2RETRY
00 (Condition other than below)/
01 (Retry standby)/02 (Restart standby)
dC-40 Detailed monitor for icon 2NRDY
00 (Preparation completed condition other than below
IRDY=OFF)/
01 (Trip occurred)/02 (Power supply abnormality)/
03 (Resetting)/04 (STO)/05 (Standby)/
06 (Data inconsistency Others (including no FB, consistency
of settings of A and B phases, etc.))/
07 (Sequence abnormality)/08 (Free run)/
09 (Forced stop)
To Next Page
