Monitors Related to the Program Function EzSQ
Code Name Data range
db-01 Program download monitor 00 (Without a program)/01 (With a program)
db-02 Program number monitor 0000 to 9999
db-03 Program counter (Task-1) 1 to 1024
db-04 Program counter (Task-2) 1 to 1024
db-05 Program counter (Task-3) 1 to 1024
db-06 Program counter (Task-4) 1 to 1024
db-07 Program counter (Task-5) 1 to 1024
db-08 User monitor 0 -2147483647 to 2147483647
db-10 User monitor 1 -2147483647 to 2147483647
db-12 User monitor 2 -2147483647 to 2147483647
db-14 User monitor 3 -2147483647 to 2147483647
db-16 User monitor 4 -2147483647 to 2147483647
db-18 Analog output monitor YA0 0 to 10000
db-19 Analog output monitor YA1 0 to 10000
db-20 Analog output monitor YA2 0 to 10000
db-21 to
db-23
Reserved -
Monitors Related to PID Function
Code Name Data range
db-30 PID1 feedback data 1 monitor
0.00 to 100.00 (%)
(adjustable in [AH-04][AH-05][AH-06])
db-32 PID1 feedback data 2 monitor
db-34 PID1 feedback data 3 monitor
db-36 PID2 feedback data monitor
0.00 to 100.00 (%)
(adjustable in [AJ-04][AJ-05][AJ-06])
db-38 PID3 feedback data monitor
0.00 to 100.00 (%)
(adjustable in [AJ-24][AJ-25][AJ-26])
db-40 PID4 feedback data monitor
0.00 to 100.00 (%)
(adjustable in [AJ-44][AJ-45][AJ-46])
db-42
PID1 target value monitor after cal-
culation
0.00 to 100.00 (%)(adjustable in [AH-04][AH-05][AH-06])
db-44 PID1 feedback data
db-50 PID1 output monitor -100.00 to 100.00 (%)
db-51 PID1 deviation monitor -200.00 to 200.00 (%)
db-52 PID1 deviation 1 monitor -200.00 to 200.00 (%)
db-53 PID1 deviation 2 monitor -200.00 to 200.00 (%)
db-54 PID1 deviation 3 monitor -200.00 to 200.00 (%)
db-55 PID2 output monitor -100.00 to 100.00 (%)
db-56 PID2 deviation monitor -200.00 to 200.00 (%)
db-57 PID3 output monitor -100.00 to 100.00 (%)
db-58 PID3 deviation monitor -200.00 to 200.00 (%)
db-59 PID4 output monitor -100.00 to 100.00 (%)
db-60 PID4 deviation monitor -200.00 to 200.00 (%)
db-61 PID current P gain monitor 0 to 100.00 (%)
db-62 PID current I gain monitor 0.0 to 3600.0 (s)
db-63 PID current D gain monitor 0.00 to 100.00 (s)
db-64 PID feed-forward monitor -100.00 to 100.00 (%)
