Omron RX2 Series User Manual

C - 13
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-2 Monitor List
C
Monitor of Retry State
Code Name Data range
dE-31
Retry monitor 1 Factor 1 to 255
Retry monitor 1 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 1 Output frequency(with sign)(LOW)
Retry monitor 1 Output current 0 to 65535
Retry monitor 1 P-N DC voltage 0 to 10000
Retry monitor 1 Inverter state
0 to 8
*1
Retry monitor 1 LAD state
0 to 5
*1
Retry monitor 1 INV control mode
0 to 11
*1
Retry monitor 1 Limit state
0 to 6
*1
Retry monitor 1 Special state
0 to 6
*1
Retry monitor 1 RUN time(HIGT)
0 to 1000000
Retry monitor 1 RUN time(LOW)
Retry monitor 1 Power ON time(HIGT)
0 to 1000000
Retry monitor 1 Power ON time(LOW)
Retry monitor 1 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 1 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 1 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
dE-32
Retry monitor 2 Factor 1 to 255
Retry monitor 2 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 2 Output frequency(with sign)(LOW)
Retry monitor 2 Output current 0 to 65535
Retry monitor 2 P-N DC voltage 0 to 10000
Retry monitor 2 Inverter state
0 to 8
*1
Retry monitor 2 LAD state
0 to 5
*1
Retry monitor 2 INV control mode
0 to 11
*1
Retry monitor 2 Limit state
0 to 6
*1
Retry monitor 2 Special state
0 to 6
*1
Retry monitor 2 RUN time(HIGT)
0 to 2000000
Retry monitor 2 RUN time(LOW)
Retry monitor 2 Power ON time(HIGT)
0 to 2000000
Retry monitor 2 Power ON time(LOW)
Retry monitor 2 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 2 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 2 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
