Omron RX2 Series User Manual

Appendices C Table of Parameters
C - 14
High-function General-purpose Inverter RX2 Series User’s Manual
dE-33
Retry monitor 3 Factor 1 to 255
Retry monitor 3 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 3 Output frequency(with sign)(LOW)
Retry monitor 3 Output current 0 to 65535
Retry monitor 3 P-N DC voltage 0 to 10000
Retry monitor 3 Inverter state
0 to 8
*1
Retry monitor 3 LAD state
0 to 5
*1
Retry monitor 3 INV control mode
0 to 11
*1
Retry monitor 3 Limit state
0 to 6
*1
Retry monitor 3 Special state
0 to 6
*1
Retry monitor 3 RUN time(HIGT)
0 to 1000000
Retry monitor 3 RUN time(LOW)
Retry monitor 3 Power ON time(HIGT)
0 to 1000000
Retry monitor 3 Power ON time(LOW)
Retry monitor 3 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 3 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 3 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
dE-34
Retry monitor 4 Factor 1 to 255
Retry monitor 4 Output frequency(with sign)(HIGT)
-59000 to 59000
Retry monitor 4 Output frequency(with sign)(LOW)
Retry monitor 4 Output current 0 to 65535
Retry monitor 4 P-N DC voltage 0 to 10000
Retry monitor 4 Inverter state
0 to 8
*1
Retry monitor 4 LAD state
0 to 5
*1
Retry monitor 4 INV control mode
0 to 11
*1
Retry monitor 4 Limit state
0 to 6
*1
Retry monitor 4 Special state
0 to 6
*1
Retry monitor 4 RUN time(HIGT)
0 to 1000000
Retry monitor 4 RUN time(LOW)
Retry monitor 4 Power ON time(HIGT)
0 to 1000000
Retry monitor 4 Power ON time(LOW)
Retry monitor 4 Absolute time (year, month)
00 to 99 (BCD code)
01 to 12 (BCD code)
Retry monitor 4 Absolute time (day, day of the week)
01 to 31 (BCD code)
00 to 06 (BCD code)
Retry monitor 4 Absolute time (hour, minute)
00 to 23 (BCD code)
00 to 59 (BCD code)
Code Name Data range
