Appendices C Table of Parameters
C - 22
High-function General-purpose Inverter RX2 Series User’s Manual
AA202 -
Sub speed input source selec-
tion, 2nd-motor
00 (Disabled)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)/14 (Program function)/
15 (PID calculation)/16 (Reserved)
00
AA204 ○ Sub speed setting, 2nd-motor 0.00 to 590.00 (Hz) 0.00
AA205 -
Calculation symbol selection for
Speed reference, 2nd-motor
00 (Disabled)/01 (Addition)/02 (Subtraction)/
03 (Multiplication)
00
AA206 ○
Add frequency setting,
2nd-motor
-590.00 to 590.00 (Hz) 0.00
AA211 -
Run-command input source
selection, 2nd-motor
00 ([FW]/[RV] terminal)/01 (3 wire)/
02 (RUN key on LCD operator)/03 (RS485)/
04 (Option 1)/05 (Option 2)/06 (Option 3)
00
*1
AA214 -
RUN-direction restriction,
2nd-motor
00 (No limitation)/01 (Only normal rotation)/
02 (Only reverse rotation)
00
AA215 -
STOP mode selection,
2nd-motor
00 (Deceleration stop)/01 (Free run stop) 00
AA221 -
Control mode selection,
2nd-motor
00 ([V/f] Fixed torque characteristics (IM))/
01 ([V/f] Reducing torque characteristics (IM))/
02 ([V/f] Free V/f (IM))/03 ([V/f] Auto torque boost (IM))/
04 ([V/f with sensor] Fixed torque characteristics (IM)/
05 ([V/f with sensor] Reduced torque characteristics (IM)/
06 ([V/f with sensor] Free V/f (IM)/
07 ([V/f with sensor] Auto torque boost (IM)/
08 (Sensorless vector control (IM))/
09 (Zero-Hz range sensorless vector control (IM))
*2
/
10 (Vector control with sensor (IM))
*2
/
11 (Synchronous start type sensorless vector control
(SM/PMM))/
12 (IVMS start type sensorless vector control (SM/PMM))
*3
00
AA223 -
Vector control mode selection,
2nd-motor
00 (Speed/torque control mode)/
01 (Pulse string position control mode)/
02 (Absolute position control mode)/
03 (High-resolution absolute position control mode)
00
*1. It is a default value when Default Value Selection (Ub-02) is set to 01.
*2. Cannot be selected if [Ub-03] duty spec selection is 01 (LD) or 00 (VLD).
*3. Cannot be selected if [Ub-03] duty spec selection is 00 (VLD).
