Omron RX2 Series User Manual

C - 23
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
Ab-01 - Frequency conversion gain 0.01 to 100.00 1.00
Ab-03 - Multistep speed selection
00 (16th speed: binary (CF1 to CF4))/
01 (8th speed: bit (SF1 to SF7))
00
Ab110 ○ Multispeed-0 setting, 1st-motor 0.00 to 590.00 (Hz) 0.00
Ab-11 ○ Multispeed-1 setting 0.00 to 590.00 (Hz) 0.00
Ab-12 ○ Multispeed-2 setting 0.00 to 590.00 (Hz) 0.00
Ab-13 ○ Multispeed-3 setting 0.00 to 590.00 (Hz) 0.00
Ab-14 ○ Multispeed-4 setting 0.00 to 590.00 (Hz) 0.00
Ab-15 ○ Multispeed-5 setting 0.00 to 590.00 (Hz) 0.00
Ab-16 ○ Multispeed-6 setting 0.00 to 590.00 (Hz) 0.00
Ab-17 ○ Multispeed-7 setting 0.00 to 590.00 (Hz) 0.00
Ab-18 ○ Multispeed-8 setting 0.00 to 590.00 (Hz) 0.00
Ab-19 ○ Multispeed-9 setting 0.00 to 590.00 (Hz) 0.00
Ab-20 ○ Multispeed-10 setting 0.00 to 590.00 (Hz) 0.00
Ab-21 ○ Multispeed-11 setting 0.00 to 590.00 (Hz) 0.00
Ab-22 ○ Multispeed-12 setting 0.00 to 590.00 (Hz) 0.00
Ab-23 ○ Multispeed-13 setting 0.00 to 590.00 (Hz) 0.00
Ab-24 ○ Multispeed-14 setting 0.00 to 590.00 (Hz) 0.00
Ab-25 ○ Multispeed-15 setting 0.00 to 590.00 (Hz) 0.00
Ab210 ○ Multispeed-0 setting, 2nd-motor 0.00 to 590.00 (Hz) 0.00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
AC-01 -
Acceleration/ Deceleration time
input selection
00 (Parameter setting)/01 (Option 1)/
02 (Option 2)/03 (Option 3)/04 (DriveProgramming)
00
AC-02 -
Acceleration/ Deceleration
Selection
00 (Common)/
01 (Multi-stage acceleration/deceleration)
00
AC-03 - Acceleration curve selection
00 (Linear)/01 (S-shaped)/02 (U-shaped)/
03 (Reverse U-shaped)/04 (Elevator S-shaped)
00
AC-04 - Deceleration curve selection
00 (Linear)/01 (S-shaped)/02 (U-shaped)/
03 (Reverse U-shaped)/04 (Elevator S-shaped)
00
AC-05 -
Acceleration curve constant set-
ting
1 to 10 2
AC-06 -
Deceleration curve constant set-
ting
1 to 10 2
AC-08 -
EL-S-curve ratio @start of
acceleration
0 to 100 25
AC-09 -
EL-S-curve ratio @end of accel-
eration
0 to 100 25
AC-10 -
EL-S-curve ratio @start of
deceleration
0 to 100 25
AC-11 -
EL-S-curve ratio @end of decel-
eration
0 to 100 25
AC115 -
Select method to switch to
Accel2/Decel2 Profile, 1st-motor
00 ([2CH] terminal)/01 (Parameter setting)/
02 (Switching normal/reverse rotation)
00
AC116 ○
Accel1 to Accel2 Frequency
transition point, 1st-motor
0.00 to 590.00 (Hz) 0.00
AC117 ○
Decel1 to Decel2 Frequency
transition point, 1st-motor
0.00 to 590.00 (Hz) 0.00
AC120 ○
Acceleration time setting 1,
1st-motor
0.00 to 3600.00 (s) 30.00
AC122 ○
Deceleration time setting 1,
1st-motor
0.00 to 3600.00 (s) 30.00
AC124 ○
Acceleration time setting 2,
1st-motor
0.00 to 3600.00 (s) 15.00
