Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
AF101 - DC braking selection, 1st-motor
00 (Disabled)/01 (Enabled)/
02 (Frequency command)
00
AF102 - Braking type selection, 1st-motor
00 (DC braking)/01 (Speed servo lock)/
02 (Position servo lock)
00
AF103 ○ DC braking frequency, 1st-motor 0.00 to 590.00 (Hz) 0.50
AF104 ○ DC braking delay time, 1st-motor 0.00 to 5.00 (s) 0.00
AF105 ○
DC braking force setting,
1st-motor
0 to 100 (%) (with internal limitation) 30
AF106 ○
DC braking active time at stop,
1st-motor
0.00 to 60.00 (s) 0.00
AF107 ○
DC braking operation method
selection, 1st-motor
00 (Edge mode)/01 (Level mode) 01
AF108 ○
DC braking force at start,
1st-motor
0 to 100 (%) (with internal limitation) 30
AF109 ○
DC braking active time at start,
1st-motor
0.00 to 60.00 (s) 0.00
AF120 -
ContactorControl Enable,
1st-motor
00 (Disabled)/01 (Enabled: primary side)/
02 (Enabled: secondary side)
00
AF121 ○ Run delay time, 1st-motor 0.00 to 2.00 (s) 0.20
AF122 ○ Contactor off delay time, 1st-motor 0.00 to 2.00 (s) 0.10
AF123 ○
Contactor answer back check
time, 1st-motor
0.00 to 5.00 (s) 0.10
AF130 - Brake Control Enable, 1st-motor
00 (Disabled)/
01 (Brake control 1 common in forward/
reverse rotation)/
02 (Brake control 1 forward/reverse set individu-
ally)/
03 (Brake control 2)
00
AF131 ○
Brake Wait Time for Release,
1st-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF132 ○
Brake Wait Time for Accel. ,
1st-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF133 ○
Brake Wait Time for Stopping,
1st-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF134 ○
Brake Wait Time for Confirmation,
1st-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF135 ○
Brake Release Frequency Setting,
1st-motor (Forward side)
0.00 to 590.00 (Hz) 0.00
AF136 ○
Brake Release Current Setting,
1st-motor (Forward side)
(0.0 to 2.0)
× Inverter rated current (A)
*1
1.0 × Inverter
rated current
AF137 ○
Braking Frequency, 1st-motor
(Forward side)
0.00 to 590.00 (Hz) 0.00
AF138 ○
Brake Wait Time for Release,
1st-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF139 ○
Brake Wait Time for Accel. ,
1st-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF140 ○
Brake Wait Time for Stopping,
1st-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF141 ○
Brake Wait Time for Confirmation,
1st-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF142 ○
Brake Release Frequency Setting,
1st-motor (Reverse side)
0.00 to 590.00 (Hz) 0.00
AF143 ○
Brake Release Current Setting,
1st-motor (Reverse side)
(0.0 to 2.0)
× Inverter rated current (A)
*1
1.0 × Inverter
rated current
AF144 ○
Braking Frequency, 1st-motor
(Reverse side)
0.00 to 590.00 (Hz) 0.00
AF150 ○ Brake open delay time, 1st-motor 0.00 to 2.00 (s) 0.20
AF151 ○ Brake close delay time, 1st-motor 0.00 to 2.00 (s) 0.20
