Appendices C Table of Parameters
C - 28
High-function General-purpose Inverter RX2 Series User’s Manual
AF152 ○
Brake answer back check time,
1st-motor
0.00 to 5.00 (s) 0.10
AF153 ○
Servo lock/ DC injection time at
start, 1st-motor
0.00 to 10.00 (s) 0.60
AF154 ○
Servo lock/ DC injection time at
stop, 1st-motor
0.00 to 10.00 (s) 0.60
AF201 - DC braking selection, 2nd-motor
00 (Disabled)/01 (Enabled)/
02 (Frequency command)
00
AF202 - Braking type selection, 2nd-motor
00 (DC braking)/01 (Speed servo lock)/
02 (Position servo lock)
00
AF203 ○ DC braking frequency, 2nd-motor 0.00 to 590.00 (Hz) 0.50
AF204 ○ DC braking delay time, 2nd-motor 0.00 to 5.00 (s) 0.00
AF205 ○
DC braking force setting,
2nd-motor
0 to 100 (%) (with internal limitation) 30
AF206 ○
DC braking active time at stop,
2nd-motor
0.00 to 60.00 (s) 0.00
AF207 ○
DC braking operation method
selection, 2nd-motor
00 (Edge mode)/01 (Level mode) 01
AF208 ○
DC braking force at start,
2nd-motor
0 to 100 (%) (with internal limitation) 30
AF209 ○
DC braking active time at start,
2nd-motor
0.00 to 60.00 (s) 0.00
AF220 -
ContactorControl Enable,
2nd-motor
00 (Disabled)/01 (Enabled: primary side)/
02 (Enabled: secondary side)
00
AF221 ○ Run delay time, 2nd-motor 0.00 to 2.00 (s) 0.20
AF222 ○
Contactor off delay time,
2nd-motor
0.00 to 2.00 (s) 0.10
AF223 ○
Contactor answer back check
time, 2nd-motor
0.00 to 5.00 (s) 0.10
AF230 - Brake Control Enable, 2nd-motor
00 (Disabled)/
01 (Brake control common in forward/
reverse rotation)/
02 (Brake control 1 forward/reverse set individually)
00
AF231 ○
Brake Wait Time for Release,
2nd-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF232 ○
Brake Wait Time for Accel. ,
2nd-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF233 ○
Brake Wait Time for Stopping,
2nd-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF234 ○
Brake Wait Time for Confirmation,
2nd-motor (Forward side)
0.00 to 5.00 (s) 0.00
AF235 ○
Brake Release Frequency Setting,
2nd-motor (Forward side)
0.00 to 590.00 (Hz) 0.00
AF236 ○
Brake Release Current Setting,
2nd-motor (Forward side)
(0.0 to 2.0)
× Inverter rated current (A)
*1
1.0 × Inverter
rated current
AF237 ○
Braking Frequency, 2nd-motor
(Forward side)
0.00 to 590.00 (Hz) 0.00
AF238 ○
Brake Wait Time for Release,
2nd-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF239 ○
Brake Wait Time for Accel. ,
2nd-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF240 ○
Brake Wait Time for Stopping,
2nd-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF241 ○
Brake Wait Time for Confirmation,
2nd-motor (Reverse side)
0.00 to 5.00 (s) 0.00
AF242 ○
Brake Release Frequency Setting,
2nd-motor (Reverse side)
0.00 to 590.00 (Hz) 0.00
AF243 ○
Brake Release Current Setting,
2nd-motor (Reverse side)
(0.0 to 2.0)
× Inverter rated current (A)
*1
1.0 × Inverter
rated current
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
To Next Page
