C - 29
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
AF244 ○
Braking Frequency, 2nd-motor
(Reverse side)
0.00 to 590.00 (Hz) 0.00
AF250 ○ Brake open delay time, 2nd-motor 0.00 to 2.00 (s) 0.20
AF251 ○ Brake close delay time, 2nd-motor 0.00 to 2.00 (s) 0.20
AF252 ○
Brake answer back check time,
2nd-motor
0.00 to 5.00 (s) 0.10
AF253 ○
Servo lock/ DC injection time at
start, 2nd-motor
0.00 to 10.00 (s) 0.60
AF254 ○
Servo lock/ DC injection time at
stop, 2nd-motor
0.00 to 10.00 (s) 0.60
*1. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00 (A,V). When the data of
[CF-11] Resister data selection is not set to 00 (A,V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A,V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
AG101 ○ Jump frequency 1, 1st-motor 0.00 to 590.00 (Hz) 0.00
AG102 ○ Jump frequency width 1, 1st-motor 0.00 to 10.00 (Hz) 0.00
AG103 ○ Jump frequency 2, 1st-motor 0.00 to 590.00 (Hz) 0.00
AG104 ○ Jump frequency width 2, 1st-motor 0.00 to 10.00 (Hz) 0.00
AG105 ○ Jump frequency 3, 1st-motor 0.00 to 590.00 (Hz) 0.00
AG106 ○ Jump frequency width 3, 1st-motor 0.00 to 10.00 (Hz) 0.00
AG110 ○
Acceleration stop frequency set-
ting, 1st-motor
0.00 to 590.00 (Hz) 0.00
AG111 ○
Acceleration stop time setting,
1st-motor
0.0 to 60.0 (s) 0.0
AG112 ○
Deceleration stop frequency set-
ting, 1st-motor
0.00 to 590.00 (Hz) 0.00
AG113 ○
Deceleration stop time setting,
1st-motor
0.0 to 60.0 (s) 0.0
AG-20 ○ Jogging frequency 0.00 to 10.00 (Hz) 6.00
AG-21 - Jogging stop mode selection
00 (Disabled during FRS operation at stop)/
01 (Disabled during deceleration stop operation)/
02 (Disabled during DB operation at stop)/
03 (Enabled during FRS operation at stop)/
04 (Enabled during deceleration stop operation)/
05 (Enabled during DB operation at stop)
00
AG201 ○ Jump frequency 1, 2nd-motor 0.00 to 590.00 (Hz) 0.00
AG202 ○
Jump frequency width 1,
2nd-motor
0.00 to 10.00 (Hz) 0.00
AG203 ○ Jump frequency 2, 2nd-motor 0.00 to 590.00 (Hz) 0.00
AG204 ○
Jump frequency width 2,
2nd-motor
0.00 to 10.00 (Hz) 0.00
AG205 ○ Jump frequency 3, 2nd-motor 0.00 to 590.00 (Hz) 0.00
AG206 ○
Jump frequency width 3,
2nd-motor
0.00 to 10.00 (Hz) 0.00
AG210 ○
Acceleration stop frequency set-
ting, 2nd-motor
0.00 to 590.00 (Hz) 0.00
AG211 ○
Acceleration stop time setting,
2nd-motor
0.0 to 60.0 (s) 0.0
AG212 ○
Deceleration stop frequency set-
ting, 2nd-motor
0.00 to 590.00 (Hz) 0.00
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
