Appendices C Table of Parameters
C - 30
High-function General-purpose Inverter RX2 Series User’s Manual
AG213 ○
Deceleration stop time setting,
2nd-motor
0.0 to 60.0 (s) 0.0
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
AH-01 - PID1 enable
00 (Disabled)/
01 (Enabled Without reverse output)/
02 (Enabled With reverse output)
00
AH-02 - PID1 deviation inverse 00 (Disabled)/01 (Enabled) 00
AH-03 - Unit selection for PID1
See <Unit options> on page C-70 at the end of Appendi-
ces C
01
AH-04 ○ PID1 scale adjustment (0%) -10000 to 10000 0
AH-05 ○ PID1 scale adjustment (100%) -10000 to 10000 10000
AH-06 ○
PID1 scale adjustment (point posi-
tion)
0 to 4 2
AH-07 -
Input source selection of Set-point
for PID1
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
07
AH-10 ○ Set-point-1 setting for PID1 -100.00 to 100.00
*1
0.00
AH-12 ○
PID1 Multi stage set-point 1 set-
ting
-100.00 to 100.00
*1
0.00
AH-14 ○
PID1 Multi stage set-point 2 set-
ting
-100.00 to 100.00
*1
0.00
AH-16 ○
PID1 Multi stage set-point 3 set-
ting
-100.00 to 100.00
*1
0.00
AH-18 ○
PID1 Multi stage set-point 4 set-
ting
-100.00 to 100.00
*1
0.00
AH-20 ○
PID1 Multi stage set-point 5 set-
ting
-100.00 to 100.00
*1
0.00
AH-22 ○
PID1 Multi stage set-point 6 set-
ting
-100.00 to 100.00
*1
0.00
AH-24 ○
PID1 Multi stage set-point 7 set-
ting
-100.00 to 100.00
*1
0.00
AH-26 ○
PID1 Multi stage set-point 8 set-
ting
-100.00 to 100.00
*1
0.00
AH-28 ○
PID1 Multi stage set-point 9 set-
ting
-100.00 to 100.00
*1
0.00
AH-30 ○
PID1 Multi stage set-point 10 set-
ting
-100.00 to 100.00
*1
0.00
AH-32 ○
PID1 Multi stage set-point 11 set-
ting
-100.00 to 100.00
*1
0.00
AH-34 ○
PID1 Multi stage set-point 12 set-
ting
-100.00 to 100.00
*1
0.00
AH-36 ○
PID1 Multi stage set-point 13 set-
ting
-100.00 to 100.00
*1
0.00
AH-38 ○
PID1 Multi stage set-point 14 set-
ting
-100.00 to 100.00
*1
0.00
AH-40 ○
PID1 Multi stage set-point 15 set-
ting
-100.00 to 100.00
*1
0.00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
