C - 31
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
AH-42 -
Input source selection of Set-point
2 for PID1
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
00
AH-44 ○ Set-point 2 setting for PID1 -100.00 to 100.00 (%)
*1
0.00
AH-46 -
Input source selection of Set-point
3 for PID1
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
00
AH-48 ○ Set-point 3 setting for PID1 -100.00 to 100.00 (%)
*1
0.00
AH-50 -
Calculation symbol selection of
Set-point 1 for PID1
01 (Addition)/02 (Subtraction)/03 (Multiplication)/
04 (Division)/05(Minimum deviation)/
06(Maximum deviation)
01
AH-51 -
Input source selection of Process
data 1 for PID1
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/08 (RS 485)/09 (Option 1)/10 (Option 2)/
11 (Option 3)/12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
01
AH-52 -
Input source selection of Process
data 2 for PID1
00
AH-53 -
Input source selection of Process
data 3 for PID1
00
AH-54 -
Calculation symbol selection of
Process data for PID1
01 (Addition)/02 (Subtraction)/03 (Multiplication)/
04 (Division)/05(Square root of FB1)/
06(Square root of FB2)/07(Square root of (FB1-FB2))/
08(Average of PV-1 to PV-3)/
09(Minimum data of PV-1 to PV-3)/
10(Maximum data of PV-1 to PV-3)
01
AH-60 -
PID1 gain change method selec-
tion
00 (Only gain 1)/01 ([PRO] terminal switch) 00
AH-61 ○ PID1 proportional gain 1 0.0 to 100.0 1.0
AH-62 ○ PID1 integral time constant 1 0.0 to 3600.0 (s) 1.0
AH-63 ○ PID1 derivative gain 1 0.00 to 100.00 (s) 0.00
AH-64 ○ PID1 proportional gain 2 0.0 to 100.0 0.0
AH-65 ○ PID1 integral time constant 2 0.00 to 3600.0 (s) 0.0
AH-66 ○ PID1 derivative gain 2 0.00 to 100.00 (s) 0.00
AH-67 ○ PID1 gain change time 0 to 10000 (ms) 100
AH-70 - PID feed-forward selection
00 (Disabled)/01 (Ai1 terminal input)/
02 (Ai2 terminal input)/03 (Ai3 terminal input)/
04 (Reserved)/05 (Reserved)/06 (Reserved)
00
AH-71 ○ PID1 output range 0.00 to 100.00 (%) 0.00
AH-72 ○ PID1 deviation over level 0.00 to 100.00 (%) 3.00
AH-73 ○
PID1 feedback compare signal
turn-off level
0.00 to 100.00 (%) 100.00
AH-74 ○
PID1 feedback compare signal
turn-on level
0.00 to 100.00 (%) 0.00
AH-75 - PID soft-start function enable 00 (Disabled)/01 (Enabled) 00
AH-76 ○ PID soft-start target level 0.00 to 100.00 (%) 100.00
AH-78 ○
Acceleration time setting for PID
soft-start function
0.00 to 3600.00 (s) 30.00
AH-80 ○ PID soft-start time 0.00 to 100.00 (s) 0.00
AH-81 -
PID soft start error detection
enable
00 (Disabled)/01 (Enabled: error output)/
02 (Enabled: warning)
00
AH-82 ○ PID soft start error detection level 0.00 to 100.00 (%) 0.00
AH-85 - PID sleep trigger selection 00 (Disabled)/01 (Low output)/02 ([SLEP] terminal) 00
AH-86 ○ PID sleep start level 0.00 to 590.00 (Hz) 0.00
AH-87 ○ PID sleep active time 0.00 to 100.00 (s) 0.00
AH-88 -
Setpoint boost before PID sleep
enable
00 (Disabled)/01 (Enabled) 00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
