Appendices C Table of Parameters

C - 32

High-function General-purpose Inverter RX2 Series User’s Manual

AH-89 ○ Setpoint boost time 0.00 to 100.00 (s) 0.00

AH-90 ○ Setpoint boost value 0.00 to 100.00 (%) 0.00

AH-91 ○

Minimum RUN time befor PID

sleep

0.00 to 100.00 (s) 0.00

AH-92 ○ Minimum active time of PID sleep 0.00 to 100.00 (s) 0.00

AH-93 - PID sleep trigger selection

01 (Deviation amount)/02 (Low feedback)/

03 ([WAKE] terminal)

AH-94 ○ PID wake start level 0.00 to 100.00 (%) 0.00

AH-95 ○ PID wake start time 0.00 to 100.00 (s) 0.00

AH-96 ○ PID wake start deviation value 0.00 to 100.00 (%) 0.00

*1. Data range differs depending on [AH-04] to [AH-06].

Code

Codes that

can be

changed

during

operation

Name Data range

Initial

value

Note

AJ-01 - PID2 enable

00 (Disabled)/

01 (Enabled Without reverse output)/

02 (Enabled With reverse output)

AJ-02 - PID2 deviation inverse 00 (Disabled)/01 (Enabled) 00

AJ-03 - PID2 unit selection

See <Unit options> on page C-70 at the end of Appendices

AJ-04 ○ PID2 scale adjustment (0%) -10000 to 10000 0

AJ-05 ○ PID2 scale adjustment (100%) -10000 to 10000 10000

AJ-06 ○

PID2 scale adjustment (point

position)

0 to 4 2

AJ-07 -

Input source selection of

Set-point for PID2

00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/

03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/

06 (Reserved)/07 (Parameter setting)/08 (RS 485)/

09 (Option 1)/10 (Option 2)/11 (Option 3)/

12 (Pulse string input: main unit)/

13 (Pulse string input: Option)/15 (PID1 output)

AJ-10 ○ Set-point setting for PID2

-100.00 to 100.00 (%)

0.00

AJ-12 -

Input source selection of Pro-

cess data for PID2

00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/

03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/

06 (Reserved)/07 (Parameter setting)/08 (RS 485)/

09 (Option 1)/10 (Option 2)/11 (Option 3)/

12 (Pulse string input: main unit)/

13 (Pulse string input: Option)

AJ-13 ○ PID2 proportional gain 0.0 to 100.0 1.0

AJ-14 ○ PID2 integral time constant 0.0 to 3600.0 (s) 1.0

AJ-15 ○ PID2 derivative gain 0.00 to 100.00 (s) 0.00

AJ-16 ○ PID2 output range 0.00 to 100.00 (%) 0.00

AJ-17 ○ PID2 deviation over level 0.00 to 100.00 (%) 3.00

AJ-18 ○

PID2 feedback compare signal

turn-OFF level

0.00 to 100.00 (%) 100.00

AJ-19 ○

PID2 feedback compare signal

turn-ON level

0.00 to 100.00 (%) 0.00

AJ-21 - PID3 enable

00 (Disabled)/

01 (Enabled Without reverse output)/

02 (Enabled With reverse output)

AJ-22 - PID3 deviation inverse 00 (Disabled)/01 (Enabled) 00

AJ-23 - PID3 unit selection

See <Unit options> on page C-70 at the end of Appendices

AJ-24 ○ PID3 scale adjustment (0%) -10000 to 10000 0

AJ-25 ○ PID3 scale adjustment (100%) -10000 to 10000 10000

AJ-26 ○

PID3 scale adjustment (point
