C - 33
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
AJ-27 -
Input source selection of
Set-point for PID3
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
07
AJ-30 ○ Set-point setting for PID3
-100.00 to 100.00 (%)
*2
0.00
AJ-32 -
Input source selection of Pro-
cess data for PID3
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
01
AJ-33 ○ PID3 proportional gain 0.0 to 100.0 1.0
AJ-34 ○ PID3 integral time constant 0.00 to 3600.0 (s) 1.0
AJ-35 ○ PID3 derivative gain 0.0 to 100.00 (s) 0.00
AJ-36 ○ PID3 output range 0.00 to 100.00 (%) 0.00
AJ-37 ○ PID3 deviation over level 0.00 to 100.00 (%) 3.00
AJ-38 ○
PID3 feedback compare signal
turn-OFF level
0.00 to 100.00 (%) 100.00
AJ-39 ○
PID3 feedback compare signal
turn-ON level
0.00 to 100.00 (%) 0.00
AJ-41 - PID4 enable
00 (Disabled)/
01 (Enabled Without reverse output)/
02 (Enabled With reverse output)
00
AJ-42 - PID4 deviation inverse 00 (Disabled)/01 (Enabled) 00
AJ-43 - PID4 unit selection
See <Unit options> on page C-70 at the end of Appendices
C
01
AJ-44 ○ PID4 scale adjustment (0%) -10000 to 10000 0
AJ-45 ○ PID4 scale adjustment (100%) -10000 to 10000 10000
AJ-46 ○
PID4 scale adjustment (point
position)
0 to 4 2
AJ-47 -
Input source selection of
Set-point for PID4
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
07
AJ-50 ○ Set-point setting for PID4
-100.00 to 100.00 (%)
*3
0.00
AJ-52 -
Input source selection of Pro-
cess data for PID4
00 (None)/01 (Ai1 terminal input)/02 (Ai2 terminal input)/
03 (Ai3 terminal input)/04 (Reserved)/05 (Reserved)/
06 (Reserved)/07 (Parameter setting)/08 (RS 485)/
09 (Option 1)/10 (Option 2)/11 (Option 3)/
12 (Pulse string input: main unit)/
13 (Pulse string input: Option)
01
AJ-53 ○ PID4 proportional gain 0.0 to 100.0 1.0
AJ-54 ○ PID4 integral time constant 0.00 to 3600.0 (s) 1.0
AJ-55 ○ PID4 derivative gain 0.0 to 100.00 (s) 0.00
AJ-56 ○ PID4 output range 0.00 to 100.00 (%) 0.00
AJ-57 ○ PID4 deviation over level 0.00 to 100.00 (%) 3.00
AJ-58 ○
PID4 feedback compare signal
turn-OFF level
0.00 to 100.00 (%) 100.00
AJ-59 ○
PID4 feedback compare signal
turn-ON level
0.00 to 100.00 (%) 0.00
*1. Data range differs depending on [AJ-04] to [AJ-06].
*2. Data range differs depending on [AJ-24] to [AJ-26].
*3. Data range differs depending on [AJ-44] to [AJ-46].
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
