Omron RX2 Series User Manual

2 - 35
2 Design
High-function General-purpose Inverter RX2 Series User’s Manual
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals
* The EMC filter is enabled by replacing the grounding screw equipped with short
bar with the earth terminal for enabling the EMC filter.
3G3RX2-A2150
3G3RX2-A2185
R0,T0 : M4
Earth Terminal : M6
Others : M6
3G3RX2-A2220
R0,T0 : M4
Earth Terminal: M6
Others: M8
* The EMC filter is enabled/disabled by switching the short bar connector.
3G3RX2-A4150
3G3RX2-A4180
3G3RX2-A4220
R0,T0 : M4
Earth terminal: M6
Others: M6
Arrangement of Terminals Model
R
(L1)
S
(L2)
T
(L3)
U
(T1)
V
(T2)
W
(T3)
R0
PD
(+1)
P
(+)
N
(-)
RB
(RB)
G
T0
G
Power supply input wire
Earth terminal for
enabling EMC filter
Earth terminal
(with short bar)
Motor output wire
PD-P short bar
Charge lamp
(Light when
electricity turned on)
Earth terminal
(with short bar)
Fix the short bar with
two screws.
G
R
(L1)
S
(L2)
T
(L3)
U
(T1)
V
(T2)
W
(T3)
R0
PD
(+1)
P
(+)
N
(-)
RB
(RB)
G
T0
OFF G ON
Power supply
input wire
EMC filter
disabled
EMC filter
enabled
Motor output wire
PD-P short bar
Charge lamp
(Light when electricity
turned on)
