Appendices C Table of Parameters
C - 42
High-function General-purpose Inverter RX2 Series User’s Manual
Parameter Mode (Code C)
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
CA-01 ○ Input terminal [1] function
See <List of input terminal functions> on page C-44
028
CA-02 ○ Input terminal [2] function 015
CA-03 ○ Input terminal [3] function 029
CA-04 ○ Input terminal [4] function 032
CA-05 ○ Input terminal [5] function 031
CA-06 ○ Input terminal [6] function 003
CA-07 ○ Input terminal [7] function 004
CA-08 ○ Input terminal [8] function 002
CA-09 ○ Input terminal [9] function 001
CA-10 ○ Input terminal [A] function 033
CA-11 ○ Input terminal [B] function 034
CA-21 ○
Selection of Input terminal [1] active
state
00 (Normally open)/
01 (Normally closed)
00
CA-22 ○
Selection of Input terminal [2] active
state
00
CA-23 ○
Selection of Input terminal [3] active
state
00
CA-24 ○
Selection of Input terminal [4] active
state
00
CA-25 ○
Selection of Input terminal [5] active
state
00
CA-26 ○
Selection of Input terminal [6] active
state
00
CA-27 ○
Selection of Input terminal [7] active
state
00
CA-28 ○
Selection of Input terminal [8] active
state
00
CA-29 ○
Selection of Input terminal [9] active
state
00
CA-30 ○
Selection of Input terminal [A] active
state
00
CA-31 ○
Selection of Input terminal [B] active
state
00
CA-41 ○ Input terminal [1] response time
0 to 400 (ms)
2
CA-42 ○ Input terminal [2] response time 2
CA-43 ○ Input terminal [3] response time 2
CA-44 ○ Input terminal [4] response time 2
CA-45 ○ Input terminal [5] response time 2
CA-46 ○ Input terminal [6] response time 2
CA-47 ○ Input terminal [7] response time 2
CA-48 ○ Input terminal [8] response time 2
CA-49 ○ Input terminal [9] response time 2
CA-50 ○ Input terminal [A] response time 2
CA-51 ○ Input terminal [B] response time 2
CA-55 ○ Multistage input determination time 0 to 2000 (ms) 0
CA-60 ○ FUP/FDN overwrite target selection 00 (Frequency command)/01 (PID1) 00
CA-61 ○ FUP/FDN data save enable 00 (Not save)/01 (Save) 00
CA-62 ○ FUP/FDN UDC selection 00 (0Hz)/01 (saved data) 00
CA-64 ○
Acceleration time setting for
FUP/FDN functions
0.00 to 3600.00 (s) 30.00
CA-66 ○
Deceleration time setting for
FUP/FDN functions
0.00 to 3600.00 (s) 30.00
