Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
<List of output terminal functions>
Function No. Abbreviation Function name
000 no Without allocation
001 RUN During operation
002 FA1 When the constant speed is attained
003 FA2 Equal to or above the set frequency
004 FA3 Set frequency only
005 FA4 Equal to or above the set frequency 2
006 FA5 Set frequency only 2
007 IRDY Operation ready completion
008 FWR During normal rotation operation
009 RVR During reverse rotation operation
010 FREF Frequency command panel
011 REF Operation command panel
012 SETM Second control under selection
016 OPO Optional output
017 AL Alarm signal
018 MJA Severe failure signal
019 OTQ Excessive torque
020 IP During instantaneous power failure
021 UV Under insufficient voltage
022 TRQ During torque limitation
023 IPS During power failure deceleration
024 RNT RUN time elapsed
025 ONT Power ON time elapsed
026 THM Electronic thermal warning
027 THC Electronic thermal warning
029 WAC Capacitor life advance notice
030 WAF Fan life advance notice
031 FR Operation command signal
032 OHF Cooling fin heating advance notice
033 LOC Low current signal
034 LOC2 Low current signal 2
035 OL Overload advance notice
036 OL2 Overload advance notice 2
037 BRK Brake release
038 BER Brake abnormality
039 CON Contactor control
040 ZS 0 Hz detection signal
041 DSE Excessive speed deviation
042 PDD Excessive positional deviation
043 POK Positioning completed
044 PCMP Pulse count compare-match output
045 OD PID excessive deviation
046 FBV PID feedback comparison
047 OD2 PID2 excessive deviation
048 FBV2 PID2 feedback comparison
049 NDc Communication disconnection
050 Ai1Dc Analog disconnection Ai1
051 Ai2Dc Analog disconnection Ai2
052 Ai3Dc Analog disconnection Ai3
056 WCAi1 Window comparator Ai1
057 WCAi2 Window comparator Ai2
058 WCAi3 Window comparator Ai3
