Appendices C Table of Parameters
C - 54
High-function General-purpose Inverter RX2 Series User’s Manual
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
CE101 ○
Low current signal output mode
selection, 1st motor
00 (During acceleration/deceleration, at constant
speed)/
01 (Only at constant speed)
01
CE102 ○
Low current detection level 1,
1st motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE103 ○
Low current detection level 2,
1st motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE105 ○
Over current signal output mode
selection, 1st motor
00 (During acceleration/deceleration, at constant
speed)/
01 (Only at constant speed)
01
CE106 ○
Over current detection level 1,
1st motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE107 ○
Over current detection level 2,
1st motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE-10 ○
Arrival frequency setting during
acceleration 1
0.00 to 590.00 (Hz) 0.00
CE-11 ○
Arrival frequency setting during
deceleration 1
0.00 to 590.00 (Hz) 0.00
CE-12 ○
Arrival frequency setting during
acceleration 2
0.00 to 590.00 (Hz) 0.00
CE-13 ○
Arrival frequency setting during
deceleration 2
0.00 to 590.00 (Hz) 0.00
CE120 ○
Over torque level (Forward driv-
ing), 1st motor
0.0 to 500.0 (%) 100.0
CE121 ○
Over torque level (Reverse
regenerative), 1st motor
0.0 to 500.0 (%) 100.0
CE122 ○
Over torque level (Reverse driv-
ing), 1st motor
0.0 to 500.0 (%) 100.0
CE123 ○
Over torque level (Forward
regenerative), 1st motor
0.0 to 500.0 (%) 100.0
CE-30 ○
Electronic thermal warning level
(MTR)
0.00 to 100.00 (%) 80.00
CE-31 ○
Electronic thermal warning level
(CTL)
0.00 to 100.00 (%) 80.00
CE-33 ○ Zero speed detection level 0.00 to 100.00 (%) 0.50
CE-34 ○
Cooling FAN over-heat warning
level
0 to 200 (°C) 120
CE-36 ○
Accum.RUN(RNT)/Accum.Pow
er-on (ONT) time setting
0 to 100000 (hr) 0
CE-40 ○
Window comparator for [Ai1]
higher level
0 to 100 (%) 100
CE-41 ○
Window comparator for [Ai1]
lower level
0 to 100 (%) 0
CE-42 ○
Window comparator for [Ai1]
hysteresis width
0 to 10 (%) 0
CE-43 ○
Window comparator for [Ai2]
higher level
0 to 100 (%) 100
CE-44 ○
Window comparator for [Ai2]
lower level
0 to 100 (%) 0
CE-45 ○
Window comparator for [Ai2]
hysteresis width
0 to 10 (%) 0
CE-46 ○
Window comparator for [Ai3]
higher level
-100 to 100 (%) 100
CE-47 ○
Window comparator for [Ai3]
lower level
-100 to 100 (%) -100
