C - 55
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
CE-48 ○
Window comparator for [Ai3]
hysteresis width
0 to 10 (%) 0
CE-50 ○
Operation level at [Ai1] discon-
nection
0 to 100 (%) 0
CE-51 ○
Operation level selection at [Ai1]
disconnection
00 (Disabled)/01 (Enabled: out of range)
02 (Enabled: within the range)
00
CE-52 ○
Operation level at [Ai2] discon-
nection
0 to 100(%) 0
CE-53 ○
Operation level selection at [Ai2]
disconnection
00 (Disabled)/01 (Enabled: out of range)/
02 (Enabled: within the range)
00
CE-54 ○
Operation level at [Ai3] discon-
nection
-100 to 100(%) 0
CE-55 ○
Operation level selection at [Ai3]
disconnection
00 (Disabled)/01 (Enabled: out of range)/
02 (Enabled: within the range)
00
CE201 ○
Low current signal output mode
selection, 2nd-motor
00 (During acceleration/deceleration, at constant
speed)/
01 (Only at constant speed)
01
CE202 ○
Low current detection level 1,
2nd-motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE203 ○
Low current detection level 2,
2nd-motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE205 ○
Over current signal output mode
selection, 2nd-motor
00 (During acceleration/deceleration, at constant
speed)/
01 (Only at constant speed)
01
CE206 ○
Over current detection level 1,
2nd-motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE207 ○
Over current detection level 2,
2nd-motor
(0.0 to 2.0)
× Inverter rated current
*1
1.0
× Inverter rated
current
CE220 ○
Over torque level (Forward driv-
ing), 2nd-motor
0.0 to 500.0 (%) 100.0
CE221 ○
Over torque level (Reverse
regenerative), 2nd-motor
0.0 to 500.0 (%) 100.0
CE222 ○
Over torque level (Reverse driv-
ing), 2nd-motor
0.0 to 500.0 (%) 100.0
CE223 ○
Over torque level (Forward
regenerative), 2nd motor
0.0 to 500.0 (%) 100.0
*1. On the parameter about the current and the voltage, the figures and the units to be handled vary in the setting path.
1) Operator or CX-Drive: 0.1 A or 0.1 V (When CX-Drive is operated, set [CF-11] Resister data selection to 00 (A,V). When the data of
[CF-11] Resister data selection is not set to 00 (A,V), it is not set or displayed correctly.)
2) Modbus: The current and the voltage vary, depending on the setting of Resister data selection [CF-11].
When [CF-11] Resister data selection is set to 00 (A,V), 0.1 A, 0.1 V
When [CF-11] Resister data selection is set to 01 (%), 0.01% (Rated ratio)
3) Drive programming: 0.01% (Rated ratio)
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
To Next Page
