Appendices C Table of Parameters
C - 56
High-function General-purpose Inverter RX2 Series User’s Manual
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
CF-01 -
RS485 communication baud rate
selection
03 (2400bps)/04 (4800bps)/05 (9600bps)/06 (19.2kbps)/
07 (38.4kbps)/08 (57.6kbps)/09 (76.8kbps)/
10 (115.2kbps)
05
CF-02 ○
RS485 communication Node allo-
cation
1 to 247 1
CF-03 ○
RS485 communication parity
selection
00 (Without parity)/
01 (Even number parity)/02 (Odd number parity)
00
CF-04 ○
RS485 communication stop-bit
selection
01 (1bit)/02 (2bit) 01
CF-05 ○
RS485 communication error
selection
00 (Error)/01 (Trip after deceleration stop)/02 (Ignore)/
03 (Free run)/04 (Deceleration stop)
02
CF-06 ○
RS485 communication timeout
setting
0.00 to 100.00 (s) 0.00
CF-07 ○
RS485 communication wait time
setting
0 to 1000 (ms) 2
CF-08 ○
RS485 communication mode
selection
01 (Modbus-RTU)/02 (EzCOM)/
03 (EzCOM management)
01
CF-11 - Resister data selection 00 (A,V)/01 (%) 00
CF-20 - EzCOM start node No. 01 to 08 1
CF-21 - EzCOM End node No. 01 to 08 1
CF-22 - EzCOM start method selection 00 (ECOM) terminal)/01 (Modbus spec) 00
CF-23 ○ EzCOM data size 01 to 05 5
CF-24 ○ EzCOM destination address 1 1 to 247 1
CF-25 ○ EzCOM destination register 1 0000 to FFFF 0000
CF-26 ○ EzCOM source register 1 0000 to FFFF 0000
CF-27 ○ EzCOM destination address 2 1 to 247 2
CF-28 ○ EzCOM destination register 2 0000 to FFFF 0000
CF-29 ○ EzCOM source register 2 0000 to FFFF 0000
CF-30 ○ EzCOM destination address 3 1 to 247 3
CF-31 ○ EzCOM destination register 3 0000 to FFFF 0000
CF-32 ○ EzCOM source register 3 0000 to FFFF 0000
CF-33 ○ EzCOM destination address 4 1 to 247 4
CF-34 ○ EzCOM destination register 4 0000 to FFFF 0000
CF-35 ○ EzCOM source register 4 0000 to FFFF 0000
CF-36 ○ EzCOM destination address 5 1 to 247 5
CF-37 ○ EzCOM destination register 5 0000 to FFFF 0000
CF-38 ○ EzCOM source register 5 0000 to FFFF 0000
CF-50 ○
USB communication Node alloca-
tion
1 to 247 1
To Next Page
