Omron RX2 Series User Manual

C - 57
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
Parameter Mode (Code H)
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
HA-01 - Auto-tuning selection
00 (Disabled)/01 (Non-rotation)/
02 (Rotation)/03 (IVMS)
00
HA-02 - RUN command selection at Auto-tuning
00 (RUN key on the LCD operator)/
01 ([AA111]/[AA211])
00
HA-03 - Online auto-tuning selection 00 (Disabled)/01 (Enabled) 00
HA110 ○ Stabilization constant, 1st-motor 0 to 1000 (%) 100
HA115 ○ Speed response for Async.M, 1st-motor 0 to 1000 (%) 100
HA120 ○
ASR gain switching mode selection,
1st-motor
00 ([CAS] terminal)/
01 (setting switch)
00
HA121 ○ ASR gain switching time setting, 1st-motor 0 to 10000 (ms) 100
HA122 ○
ASR gain mapping intermediate speed 1,
1st-motor
0.00 to 590.00 (Hz) 0.00
HA123 ○
ASR gain mapping intermediate speed 2,
1st-motor
0.00 to 590.00 (Hz) 0.00
HA124 ○
ASR gain mapping Maximum speed,
1st-motor
0.00 to 590.00 (Hz) 0.00
HA125 ○ ASR gain mapping P-gain 1, 1st-motor 0.0 to 1000.0 (%) 100.0
HA126 ○ ASR gain mapping I-gain 1, 1st-motor 0.0 to 1000.0 (%) 100.0
HA127 ○
ASR gain mapping P-gain 1 at P-control,
1st-motor
0.0 to 1000.0 (%) 100.0
HA128 ○ ASR gain mapping P-gain 2, 1st-motor 0.0 to 1000.0 (%) 100.0
HA129 ○ ASR gain mapping I-gain 2, 1st-motor 0.0 to 1000.0 (%) 100.0
HA130 ○
ASR gain mapping P-gain 2 at P-control,
1st-motor
0.0 to 1000.0 (%) 100.0
HA131 ○ ASR gain mapping P-gain 3, 1st-motor 0.0 to 1000.0 (%) 100.0
HA132 ○ ASR gain mapping I-gain 3, 1st-motor 0.0 to 1000.0 (%) 100.0
HA133 ○ ASR gain mapping P-gain 4, 1st-motor 0.0 to 1000.0 (%) 100.0
HA134 ○ ASR gain mapping I-gain 4, 1st-motor 0.0 to 1000.0 (%) 100.0
HA210 ○ Stabilization constant, 2nd-motor 0 to 1000 (%) 100
HA215 ○ Speed response for Async.M, 2nd-motor 0 to 1000 (%) 100
HA220 ○
ASR gain switching mode selection,
2nd-motor
00 ([CAS] terminal)/
01 (setting switch)
00
HA221 ○
ASR gain switching time setting,
2nd-motor
0 to 10000 (ms) 100
HA222 ○
ASR gain mapping intermediate speed 1,
2nd-motor
0.00 to 590.00 (Hz) 0.00
HA223 ○
ASR gain mapping intermediate speed 2,
2nd-motor
0.00 to 590.00 (Hz) 0.00
HA224 ○
ASR gain mapping Maximum speed,
2nd-motor
0.00 to 590.00 (Hz) 0.00
HA225 ○ ASR gain mapping P-gain 1, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA226 ○ ASR gain mapping I-gain 1, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA227 ○
ASR gain mapping P-gain 1 at P-control,
2nd-motor
0.0 to 1000.0 (%) 100.0
HA228 ○ ASR gain mapping P-gain 2, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA229 ○ ASR gain mapping I-gain 2, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA230 ○
ASR gain mapping P-gain 2 at P-control,
2nd-motor
0.0 to 1000.0 (%) 100.0
HA231 ○ ASR gain mapping P-gain 3, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA232 ○ ASR gain mapping I-gain 3, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA233 ○ ASR gain mapping P-gain 4, 2nd-motor 0.0 to 1000.0 (%) 100.0
HA234 ○ ASR gain mapping I-gain 4, 2nd-motor 0.0 to 1000.0 (%) 100.
0
