Appendices C Table of Parameters
C - 58
High-function General-purpose Inverter RX2 Series User’s Manual
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
Hb102 -
Async.Motor capacity setting,
1st-motor
0.01 to 160.00 (kW)
*1
Hb105 -
Async.Motor Maximum fre-
quency setting, 1st-motor
10.00 to 590.00 (Hz)
50.00
*2
Hb106 -
Async.Motor rated voltage,
1st-motor
1 to 1000 (V)
200 V class: 230
400 V class: 400
*2
460 (*FUF)
Hb108 -
Async.Motor rated current,
1st-motor
0.01 to 10000.00 (A)
*1
Hb110 -
Async.Motor constant R1,
1st-motor
0.000001 to 1000.000000 (Ω)
*1
Hb112 -
Async.Motor constant R2,
1st-motor
0.000001 to 1000.000000 (Ω)
*1
Hb114 -
Async.Motor constant L,
1st-motor
0.000001 to 1000.000000 (mH)
*1
Hb116 -
Async.Motor constant Io,
1st-motor
0.01 to 10000.00 (A)
*1
Hb118 -
Async.Motor constant J,
1st-motor
0.00001 to 10000.00000 (kgm
2
)
*1
Hb130 -
Minimum frequency adjust-
ment, 1st-motor
0.10 to 10.00 (Hz) 0.50
Hb131 ○
Reduced voltage start time set-
ting, 1st-motor
0 to 2000 (ms) 36
Hb140 -
Manual torque boost opera-
tional mode selection, 1st-motor
00 (Disabled)/
01 (Always enabled)/
02 (Enabled only for forward revolution)/
03 (Enabled only for reverse revolution)
01
Hb141 ○
Manual torque boost value,
1st-motor
0.0 to 20.0 (%) 0.0
Hb142 ○
Manual torque boost Peak
speed, 1st-motor
0.0 to 50.0 (%) 0.0
Hb145 - Eco drive enable, 1st-motor 00 (Disabled)/01 (Enabled) 00
Hb146 ○
Eco drive response adjustment,
1st-motor
0.0 to 100.0(%) 50.0
Hb150 -
Free-V/f frequency 1 setting,
1st-motor
0.00 to [Hb152] (Hz) 0.00
Hb151 -
Free-V/f Voltage 1 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
Hb152 -
Free-V/f frequency 2 setting,
1st-motor
[Hb150] to [Hb154] (Hz) 0.00
Hb153 -
Free-V/f Voltage 2 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
Hb154 -
Free-V/f frequency 3 setting,
1st-motor
[Hb152] to [Hb156] (Hz) 0.00
Hb155 -
Free-V/f Voltage 3 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
Hb156 -
Free-V/f frequency 4 setting,
1st-motor
[Hb154] to [Hb158] (Hz) 0.00
Hb157 -
Free-V/f Voltage 4 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
Hb158 -
Free-V/f frequency 5 setting,
1st-motor
[Hb156] to [Hb160] (Hz) 0.00
Hb159 -
Free-V/f Voltage 5 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
Hb160 -
Free-V/f frequency 6 setting,
1st-motor
[Hb158] to [Hb162] (Hz) 0.00
Hb161 -
Free-V/f Voltage 6 setting,
1st-motor
0.0 to 1000.0 (V) 0.0
To Next Page
