C - 63
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
Parameter Mode (Code o)
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
oA-10 ○
Operation mode on option card error
(SLOT-1)
00 (Error)/01 (Continue operation) 00
oA-11 ○ Communication Watch Dog Timer 0.00 to 100.00 (s) 1.00
oA-12 - Action selection at communication error
00 (Error)/
01 (Trip after deceleration stop)/02 (Ignore)/
03 (Free run)/04 (Deceleration stop)
01
oA-13 -
Run command enable option during the
option card (SLOT-1) start-up
00 (Operation command disabled)/
01 (Operation command enabled)
00
oA-20 ○
Operation mode on option card error
(SLOT-2)
00 (Error)/01 (Continue operation) 00
oA-21 ○ Communication Watch Dog Timer 0.00 to 100.00 (s) 1.00
oA-22 - Action selection at communication error
00 (Error)/
01 (Trip after deceleration stop)/02 (Ignore)/
03 (Free run)/04 (Deceleration stop)
01
oA-23 -
Run command enable option during the
option card (SLOT-2) start-up
00 (Operation command disabled)/
01 (Operation command enabled)
00
oA-30 ○
Operation mode on option card error
(SLOT-3)
00 (Error)/01 (Continue operation) 00
oA-31 ○ Communication Watch Dog Timer 0.00 to 100.00 (s) 1.00
oA-32 - Action selection at communication error
00 (Error)/
01 (Trip after deceleration stop)/02 (Ignore)/
03 (Free run)/04 (Deceleration stop)
01
oA-33 -
Run command enable option during the
option card (SLOT-3) start-up
00 (Operation command disabled)/
01 (Operation command enabled)
00
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
ob-01 - Encoder constant setting 32 to 65535 (pls) 1024
ob-02 - Encoder position selection
00 (Phase-A is leading)/
01 (Phase-B is leading)
00
ob-03 - Motor gear ratio numerator 1 to 10000 1
ob-04 - Motor gear ratio denominator 1 to 10000 1
ob-10 - Pulse train detection object selection
00 (Command)/
01 (Pulse string position command)
00
ob-11 - Mode selection of pulse train input
00 (90° phase difference)/
01 (forward/reverse rotation command and rotation
direction)/
02 (forward/reverse rotation pulse string)
01
ob-12 ○ Pulse train frequency Scale 0.05 to 200.0 (kHz) 25.00
ob-13 ○
Pulse train frequency Filter time con-
stant
0.01 to 2.00 (s) 0.10
ob-14 ○ Pulse train frequency Bias value -100.0 to 100.0 (%) 0.0
ob-15 ○ Pulse train frequency High Limit 0.0 to 100.0 (%) 100.0
ob-16 ○
Pulse train frequency detection low
level
0.0 to 100.0 (%) 0.0
To Next Page
