Appendices C Table of Parameters
C - 62
High-function General-purpose Inverter RX2 Series User’s Manual
Hd203 - Sync.Motor poles setting, 2nd-motor 2 to 48 (poles)
*1
Hd204 -
Sync.Base frequency setting,
2nd-motor
10.00 to 590.00 (Hz)
*1
Hd205 -
Sync.Maximum frequency setting,
2nd-motor
10.00 to 590.00 (Hz)
*1
Hd206 - Sync.Motor rated voltage, 2nd-motor 1 to 1000 (V)
*1
Hd208 - Sync.Motor rated current, 2nd-motor 0.01 to 10000.00 (A)
*1
Hd210 - Sync.Motor constant R, 2nd-motor 0.000001 to 1000.000000 (Ω)
*1
Hd212 - Sync.Motor constant Ld, 2nd-motor 0.000001 to 1000.000000 (mH)
*1
Hd214 - Sync.Motor constant Lq, 2nd-motor 0.000001 to 1000.000000 (mH)
*1
Hd216 - Sync.Motor constant Ke, 2nd-motor 0.1 to 100000.0 (mVs/rad)
*1
Hd218 - Sync.Motor constant J, 2nd-motor
0.00001 to 10000.00000 (kgm
2
)
*1
Hd230 ○
Minimum Frequency for Sync.M-SLV,
2nd-motor
0 to 50 (%) 8
Hd231 ○
No-Load current for Sync.M-SLV,
2nd-motor
0 to 100 (%) 10
Hd232 - Starting Method for Sync.M, 2nd-motor
00 (Position estimation disabled)/
01 (Position estimation enabled)
00
Hd233 -
IMPE 0V wait number for Sync.M,
2nd-motor
0 to 255 10
Hd234 -
IMPE detect wait number for Sync.M,
2nd-motor
0 to 255 10
Hd235 -
IMPE detect number for Sync.M,
2nd-motor
0 to 255 30
Hd236 -
IMPE voltage gain for Sync.M,
2nd-motor
0 to 200 (%) 100
Hd237 -
IMPE Mg-pole position offset,
2nd-motor
0 to 359 (deg) 0
*1. Varies depending on inverter models and settings of duty rating.
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
To Next Page
