C - 61
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
HC220 ○
Torque current reference filter time con-
stant, 2nd-motor
0 to 100 (ms) 2
HC221 ○
Speed feedforward compensation gain,
2nd-motor
0 to 1000 0
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
Hd102 - Sync.Motor capacity setting, 1st-motor 0.01 to 160.00 (kW)
*1
Hd103 - Sync.Motor poles setting, 1st-motor 2 to 48 (poles)
*1
Hd104 - Sync.Base frequency setting, 1st-motor 10.00 to 590.00 (Hz)
*1
Hd105 -
Sync.Maximum frequency setting,
1st-motor
10.00 to 590.00 (Hz)
*1
Hd106 - Sync.Motor rated voltage, 1st-motor 1 to 1000 (V)
*1
Hd108 - Sync.Motor rated current, 1st-motor 0.01 to 10000.00 (A)
*1
Hd110 - Sync.Motor constant R, 1st-motor 0.000001 to 1000.000000 (Ω)
*1
Hd112 - Sync.Motor constant Ld, 1st-motor 0.000001 to 1000.000000 (mH)
*1
Hd114 - Sync.Motor constant Lq, 1st-motor 0.000001 to 1000.000000 (mH)
*1
Hd116 - Sync.Motor constant Ke, 1st-motor 0.1 to 100000.0 (mVs/rad)
*1
Hd118 - Sync.Motor constant J, 1st-motor
0.00001 to 10000.00000 (kgm
2
)
*1
Hd130 ○
Minimum Frequency for Sync.M-SLV,
1st-motor
0 to 50 (%) 8
Hd131 ○
No-Load current for Sync.M-SLV,
1st-motor
0 to 100 (%) 10
Hd132 - Starting Method for Sync.M, 1st-motor
00 (Position estimation disabled)/
01 (Position estimation enabled)
00
Hd133 -
IMPE 0V wait number for Sync.M,
1st-motor
0 to 255 10
Hd134 -
IMPE detect wait number for Sync.M,
1st-motor
0 to 255 10
Hd135 -
IMPE detect number for Sync.M,
1st-motor
0 to 255 30
Hd136 -
IMPE voltage gain for Sync.M,
1st-motor
0 to 200 (%) 100
Hd137 - IMPE Mg-pole position offset, 1st-motor 0 to 359 (deg) 0
Hd-41 ○ Carrier frequency at IVMS 0.5 to 16.0 (kHz) 2.0
Hd-42 ○ Filter gain of current detection at IVMS 0 to 1000 100
Hd-43 - Open phase voltage detection gain 00 (Gain 0)/01 (Gain 1)/02 (Gain 2)/03 (Gain 3) 00
Hd-44 ○
Open phase switching threshold com-
pensation
00 (Disabled)/01 (Enabled) 01
Hd-45 ○
P-Gain for speed control,
SM(PMM)-IVMS
0 to 1000 100
Hd-46 ○
I-Gain for speed control,
SM(PMM)-IVMS
0 to 10000 100
Hd-47 ○
Wait time for open phase switching,
SM(PMM)-IVMS
0 to 1000 15
Hd-48 ○
Limitation of decision about the drive
direction, SM(PMM)-IVMS
00 (Disabled)/01 (Enabled) 01
Hd-49 ○
Open phase voltage detection timing
adjustment, SM(PMM)-IVMS
0 to 1000 10
Hd-50 ○
Minimum pulse width adjustment,
SM(PMM)-IVMS
0 to 1000 100
Hd-51 ○ IVMS Current Limit for threshold 0 to 255 100
Hd-52 ○ IVMS threshold gain 0 to 255 100
Hd-58 ○ IVMS carrier-frequency start/end point 0 to 50 (%) 5
Hd202 - Sync.Motor capacity setting, 2nd-motor 0.01 to 160.00 (kW)
*1
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
To Next Page
