Appendices C Table of Parameters
C - 60
High-function General-purpose Inverter RX2 Series User’s Manual
Hb257 -
Free-V/f Voltage 4 setting,
2nd-motor
0.0 to 1000.0 (V) 0.0
Hb258 -
Free-V/f frequency 5 setting,
2nd-motor
[Hb256] to [Hb260] (Hz) 0.00
Hb259 -
Free-V/f Voltage 5 setting,
2nd-motor
0.0 to 1000.0 (V) 0.0
Hb260 -
Free-V/f frequency 6 setting,
2nd-motor
[Hb258] to [Hb262] (Hz) 0.00
Hb261 -
Free-V/f Voltage 6 setting,
2nd-motor
0.0 to 1000.0 (V) 0.0
Hb262 -
Free-V/f frequency 7 setting,
2nd-motor
[Hb260] to [Hb204] (Hz) 0.00
Hb263 -
Free-V/f Voltage 7 setting,
2nd-motor
0.0 to 1000.0 (V) 0.0
Hb270 ○
Slip Compensation P-gain with
encoder, 2nd-motor
0 to 1000 (%) 100
Hb271 ○
Slip Compensation I-gain with
encoder, 2nd-motor
0 to 1000 (%) 100
Hb280 ○
Output voltage gain,
2nd-motor(V/f)
0 to 255 (%) 100
*1. Varies depending on inverter models and settings of duty rating.
*2. It is a default value when Default Value Selection (Ub-02) is set to 01.
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
HC101 ○
Automatic torque boost voltage com-
pensation gain, 1st-motor
0 to 255 (%) 100
HC102 ○
Automatic torque boost slip compensa-
tion gain, 1st-motor
0 to 255 (%) 100
HC110 ○
Zero speed area limit for
Async.M-0SLV, 1st-motor
0 to 100 (%) 80
HC111 ○
Boost value at start for
Async.M-SLV/IM-CLV, 1st-motor
0 to 50 (%) 0
HC112 ○
Boost value at start for Async.M-0SLV,
1st-motor
0 to 50 (%) 10
HC113 -
Secondary resistance correction,
1st-motor
00 (Disabled)/01 (Enabled) 00
HC114 ○
Counter direction run protection selec-
tion, 1st-motor
00 (Disabled)/01 (Enabled) 00
HC120 ○
Torque current reference filter time con-
stant, 1st-motor
0 to 100 (ms) 2
HC121 ○
Speed feedforward compensation gain,
1st-motor
0 to 1000 0
HC201 ○
Automatic torque boost voltage com-
pensation gain, 2nd-motor
0 to 255 (%) 100
HC202 ○
Automatic torque boost slip compensa-
tion gain, 2nd-motor
0 to 255 (%) 100
HC210 ○
Zero speed area limit for
Async.M-0SLV, 2nd-motor
0 to 100 (%) 80
HC211 ○
Boost value at start for
Async.M-SLV/IM-CLV, 2nd-motor
0 to 50 (%) 0
HC212 ○
Boost value at start for Async.M-0SLV,
2nd-motor
0 to 50 (%) 10
HC213 -
Secondary resistance correction,
2nd-motor
00 (Disabled)/01 (Enabled) 00
HC214 ○
Counter direction run protection selec-
tion, 2nd-motor
00 (Disabled)/01 (Enabled) 00
Code
Codes that
can be
changed
during
operation
Name Data range Initial value Note
