C - 65
Appendices C Table of Parameters
High-function General-purpose Inverter RX2 Series User’s Manual
C-3 Parameter List
C
Parameter Mode (Code P)
Code
Codes that
can be
changed
during
operation
Name Data range
Initial
value
Note
PA-01 -
Mode selection for Emer-
gency-force drive
00 (Disabled)/01 (Enabled) 00
PA-02 -
Frequency reference setting at
Emergency-force drive
0.00 to 590.00 (Hz) 0.00
PA-03 -
Direction command at Emer-
gency-force drive
00 (Normal rotation)/01 (Reverse rotation) 00
PA-04 -
Commercial power supply
bypass function selection
00 (Disabled)/01 (Enabled) 00
PA-05 - Delay time of Bypass function 0.0 to 1000.0 (s) 5.0
PA-20 - Simulation mode selection 00 (Disabled)/01 (Enabled) 00
PA-21 -
Error code selection for Alarm
test
000 to 255 000
PA-22 ○
Output current monitor optional
output enable
00 (Disabled)/01 (Enabled: parameter setting [PA-23])
02 (Enabled: set from [Ai1])/03 (Enabled: set from [Ai2])/
04 (Enabled: set from [Ai3])/05 (Reserved)/
06 (Reserved)/07 (Reserved)
01
PA-23 ○
Output current monitor optional
output value setting
0.0 to 3.0 × Inverter rated current (A) 0.0
PA-24 ○
DC-bus voltage monitor optional
output enable
00 (Disabled)/01 (Enabled: parameter setting [PA-25])
02 (Enabled: set from [Ai1])/03 (Enabled: set from [Ai2])/
04 (Enabled: set from [Ai3])/05 (Reserved)/
06 (Reserved)/07 (Reserved)
01
PA-25 ○
DC-bus voltage monitor optional
value output
200 V class: 0.0 to 450.0 (Vdc)
400 V class: 0.0 to 900.0 (Vdc)
200 V
class:
270.0
400 V
class:
540.0
PA-26 ○
Output voltage monitor optional
output enable
00 (Disabled)/01 (Enabled: parameter setting [PA-27])
02 (Enabled: set from [Ai1])/03 (Enabled: set from [Ai2])/
04 (Enabled: set from [Ai3])/05 (Reserved)/
06 (Reserved)/07 (Reserved)
01
PA-27 ○
Output voltage monitor optional
output value setting
200 V class: 0.0 to 300.0 (V)
400 V class: 0.0 to 600.0 (V)
0.0
PA-28 ○
Output torque monitor optional
output enable
00 (Disabled)/01 (Enabled: parameter setting [PA-29])
02 (Enabled: set from [Ai1])/03 (Enabled: set from [Ai2])/
04 (Enabled: set from [Ai3])/05 (Reserved)/
06 (Reserved)/07 (Reserved)
01
PA-29 ○
Output torque monitor optional
output value setting
-500.0 to +500.0 (%) 0.0
PA-30 ○
Start with frequency matching
optional Setting enable
00 (Disabled)/01 (Enabled: parameter setting [PA-31])
02 (Enabled: set from [Ai1])/03 (Enabled: set from [Ai2])/
04 (Enabled: set from [Ai3])/05 (Reserved)/
06 (Reserved)/07 (Reserved)
01
PA-31 ○
Start with frequency matching
optional value setting
0.0 to 590.00 (Hz) 0.00
