PREVOST X3-45 COMMUTER User Manual

SECTION 06: ELECTRICAL
8
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual Section 06 revised release October 2021
20 On chassis welded ground stud – M6-1 stud 106 lb-in (12 Nm)
On chassis welded ground stud – M10-1.5 stud 170 lb-in (19 Nm)
21 Evaporator fan motor ground cable stud – M8-1.25 stud 170 lb-in (19 Nm)
22 Main electrical shut-off switch (Kissling type) – M12-1.75 stud 166-183 lb-in (19-21 Nm)
23 Circuit breaker (manual reset) 1/4-28 stud nut 58 lb-in (7 Nm)
24 Circuit breaker (switchable, manual reset) 1/4-24 stud nut 58 lb-in (7 Nm)
25 Ultracapacitor starting module 1/2-13 power studs 180 lb-in (20 Nm)
Ultracapacitor starting module 3/8-16 12V power stud 212 lb-in (24 Nm)
26 Bus bar, chassis ground stud, M10-1.5, ultracap starting module 240 lb-in (27 Nm)

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
