PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
12
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
4.1 Rear wheelhousing
(Entire braking system)
4.2 Rear wheelhousing
(Entire braking system)
4.3 Rear wheelhousing
5.0 Close off wheelhousing using masking paper. Prevent rust inhibitor from coming in contact with paint.
To close off wheelhousing, a polythene sheet may be
used.
6.0 Apply TECTYL 185 GW black rust inhibitor onto
wheelhousing mechanical parts.
A spray gun and pumping system are required to apply
the rust inhibitor. If the application is done inside a paint

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
