PREVOST X3-45 COMMUTER User Manual

SECTION 18: BODY
DOB 1300-1556 | X3-45 Commuter PA-1648 Maintenance Manual First release Oct 2020
55
FIGURE 100: DOOR ROLLER SUPPORTS
18. Adjust the rear latch strike plate with the
latch bolt in place.
FIGURE 101: REAR LATCH ADJUSTMENT
19. The rear latch bolt must engage not less
than 13/32” (10mm) behind the strike plate.
13/32” (10mm) min
FIGURE 102: REAR LATCH ADJUSTMENT
20. Use spacer if necessary.
FIGURE 103: REAR LATCH SPACERS
21. Adjust the rear striking plate so that there is
slight play with the latch once the door is
closed and pressed against the rubber
stops
22. Adjust the front latch strike plate with the
latch bolt in place.
FIGURE 104: FRONT LATCH STRIKE PLATE
23. The front latch bolt has to be flush with the
striker.

PREVOST X3-45 COMMUTER Specifications

General

Engine	Volvo D13
Transmission	Allison B500
Fuel Type	Diesel
Length	45 ft (13.7 m)
Width	102 in (2.6 m)
Horsepower	500 hp
GVWR	54, 000 lbs
Height	141 in
