Remote control commands

R&S

SMA100B

660User Manual 1178.3834.02 ─ 09

[:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:FALL <Fall>

Selects the fall time for the trapezoid shape of the LF generator.

Parameters:

<Fall> float

Range: 1E-6 to 100

Increment: 10E-9

*RST: 250E-6

Example: See Example "Configuring the LF generator" on page 653.

Manual operation: See "Trapezoid Rise / Fall" on page 117

[:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:HIGH <High>

Sets the high time for the trapezoid signal of the LF generator.

Parameters:

<High> float

Range: 1E-6 to 100

Increment: 10E-9

*RST: 250E-6

Example: See Example "Configuring the LF generator" on page 653.

Manual operation: See "Trapezoid High" on page 117

[:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:PERiod <Period>

Sets the period of the generated trapezoid shape. The period determines the repetition

frequency of the internal signal.

Parameters:

<Period> float

Range: 1E-6 to 100

Increment: 1E-8

*RST: 1E-3

Example: See Example "Configuring the LF generator" on page 653.

Manual operation: See "Period" on page 116

[:SOURce<hw>]:LFOutput<ch>:SHAPe:TRAPeze:RISE <Rise>

Selects the rise time for the trapezoid shape of the LF generator.

Parameters:

<Rise> float

Range: 1E-6 to 100

Increment: 10E-9

*RST: 250E-6

SOURce subsystem
